8.4 Table of alarms
Message
on display
Cause of the alarm Icon on display Alarm relay Buzzer Reset Code
shown in
alarm queue
ALx_TYPE
Control action Checks/solutions
E01 Probe B1 fault
 ashing
The alarm relay
is activated
according to the
operating mode
and/or the
dependence
OFF automatic E01 Depends on
parameter c10
Check probe connections
E02 Probe B2 fault
 ashing
OFF automatic E02 If c19=1 & c0=1/2,
as for E01, otherwise
control does not
stop.
Check probe connections
E03 Digital contact open
(immediate alarm)
 ashing
ON automatic E03 Based on parameter
c31
Check parameters
c29,c30,c31.
Check the external contact.
E04 The temperature measured
by the probe has exceeded
the threshold P26 for a time
greater than P28.
 ashing
ON automatic E04 No e ect on control Check parameters P26,P27,
P28,P29
E05 The temperature measured
by the probe has fallen
below threshold P25 for a
time greater than P28.
 ashing
ON automatic E05 No e ect on control Check parameters P25,P27,
P28,P29
E03 Digital contact open
(delayed alarm)
 ashing
ON manual E03 Based on parameter
c31
Check parameters c29,c30,
c31,P28.
Check the external contact.
E03 Digital contact open
(immediate alarm with
manual reset)
 ashing
ON manual E03 Based on parameter
c31
Check parameters
c29,c30,c31. Check the
external contact.
E06 Real time clock fault
 ashing
OFF automatic
/manual
- - Reset the clock time.
If the alarm persists,
contact service.
E07 EEPROM error, unit
parameters
 ashing
OFF automatic - Total shutdown Contact service
E08 EEPROM error, operating
parameters
 ashing
OFF automatic - Total shutdown Reset default values using
the procedure described. If
the alarm persists, contact
service.
E09 Acquisition error.
Reached max. time in
calculation of PID parameters.
 ashing
ON manual - Auto-Tuning
stopped
Reset the alarm manually
or switch the controller o
and on again
E10 Calculation error:
PID gain null.
 ashing
ON manual - Auto-Tuning
stopped
E11 Calculation error:
PID gain negative
 ashing
ON manual - Auto-Tuning
stopped
E12 Calculation error:
Integral & deriv. time negative
 ashing
ON manual - Auto-Tuning
stopped
E13 Acquisition error.
Reached max. continuous time
in calculation of gain.
 ashing
ON manual - Auto-Tuning
stopped
E14 Error when starting.
Situation not suitable
 ashing
ON manual - Auto-Tuning
stopped
The alarms that occur during the Auto-Tuning procedure are not put in
the alarm queue.
8.5 Alarm parameters
The following parameters determine the behaviour of the outputs when
an alarm is active.
8.5.1 Status of the control outputs with probe alarm
(parameter c10)
This determines the action on the control outputs when there is a control
probe alarm E01, which may be one of the four responses envisaged.
When OFF is selected, the controller shuts down immediately and the
timers are ignored. When ON is selected, on the other hand, the “Delay
between activations of two di erent relay outputs” (parameter c6) is
observed. When alarm E01 is resolved, the controller restarts normally
and the alarm output, if set, terminates the signal (see mode 5). On the
other hand, both the signal on display and the buzzer remain active until
Prg/mute is pressed.
