Carel pCO1 series Manual

Standard Shelter
Cod. +030221471 – Rel. 2.0 – April 01, 2003
30
DESCRIPTION SCR. ADD. TYPE DESCRIPTION SCR. ADD. TYPE
Type of signal from outside temperature probe
(0=NTC; 1=PT1000)
Ce 23 R/W Type AL30 (0=serious;1=min.1;2=min.2) Pc 84 R/W
pLAN connection class board 1
(0=present/rotation; 1=present/no rot.; 2=not
present)
Cf 24 R/W Type AL31 (0=serious;1=min.1;2=min.2) Pc 85 R/W
pLAN connection class board 2
(0=present/rotation; 1=present/no rot.; 2=not
present)
Cf 25 R/W Type AL32 (0=serious;1=min.1;2=min.2) Pc 86 R/W
pLAN connection class board 3
(0=present/rotation; 1=present/no rot.; 2=not
present)
Cf 26 R/W Type AL33 (0=serious;1=min.1;2=min.2) Pc 87 R/W
pLAN connection class board 4
(0=present/rotation; 1=present/no rot.; 2=not
present)
Cg 27 R/W Type AL34 (0=serious;1=min.1;2=min.2) Pc 88 R/W
pLAN connection class board 5
(0=present/rotation; 1=present/no rot.; 2=not
present)
Cg 28 R/W Type AL35 (0=serious;1=min.1;2=min.2) Pc 89 R/W
pLAN connection class board 6
(0=present/rotation; 1=present/no rot.; 2=not
present)
Cg 29 R/W Type AL36 (0=serious;1=min.1;2=min.2) Pc 90 R/W
pLAN connection class board 7
(0=present/rotation; 1=present/no rot.; 2=not
present)
Ch 30 R/W Type AL37 (0=serious;1=min.1;2=min.2) Pc 91 R/W
pLAN connection class board 8
(0=present/rotation; 1=present/no rot.; 2=not
present)
Ch 31 R/W Type AL38 (0=serious;1=min.1;2=min.2) Pc 92 R/W
Number of units in Standby mode Gb 32 R/W Type AL39 (0=serious;1=min.1;2=min.2) Pc 93 R/W
Time for automatic unit rotation in pLAN network Gb 33 R/W Type AL40 (0=serious;1=min.1;2=min.2) Pc 94 R/W
Cond. fan speed-up time G6 34 R/W Type AL41 (0=serious;1=min.1;2=min.2) Pd 95 R/W
Forcing delay for high ambient temp. Gc 35 R/W Type AL42 (0=serious;1=min.1;2=min.2) Pd 96 R/W
Forcing delay for low ambient temp. Gc 36 R/W Type AL43 (0=serious;1=min.1;2=min.2) Pd 97 R/W
Outlet fan start delay T0 37 R/W Type AL44 (0=serious;1=min.1;2=min.2) Pd 98 R/W
Outlet fan stop delay T0 38 R/W Type AL45 (0=serious;1=min.1;2=min.2) Pd 99 R/W
Integration time for P+I control T1 39 R/W Type AL46 (0=serious;1=min.1;2=min.2) Pd 100 R/W
3 position freecooling travel time T1 40 R/W Type AL47 (0=serious;1=min.1;2=min.2) Pd 101 R/W
Low pressure alarm delay T2 41 R/W Type AL48 (0=serious;1=min.1;2=min.2) Pd 102 R/W
High-low temp.-humidity alarm delays T2 42 R/W Type AL49 (0=serious;1=min.1;2=min.2) Pd 103 R/W
Relay no.4 activation delay, serious alarm T3 43 R/W Type AL50 (0=serious;1=min.1;2=min.2) Pd 104 R/W
Relay no.5 activation delay, minor alarm T3 44 R/W
Relay no.6 activation delay, minor alarm T3 45 R/W Compressor 1 operating hour threshold A7 110 R/W
Dirty filter alarm delay T4 46 R/W Compressor 2 operating hour threshold A7 111 R/W
Air flow switch alarm delay T4 47 R/W Humidifier operating hour threshold A7 112 R/W
Minimum compressor off time T5 48 R/W Fan operating hour threshold A7 113 R/W
Minimum compressor on time T5 49 R/W
Delay between compressor starts T6 50 R/W
Delay between starts of different compressors T6 51 R/W
Freecooling off time for humidity limit T7 52 R/W
Activation delay between heaters T8 53 R/W
Type AL1 (0=serious;1=min.1;2=min.2) Pb 54 R/W
Type AL2 (0=serious;1=min.1;2=min.2) Pb 55 R/W
Type AL3 (0=serious;1=min.1;2=min.2) Pb 56 R/W
Type AL4 (0=serious;1=min.1;2=min.2) Pb 57 R/W
Type AL5 (0=serious;1=min.1;2=min.2) Pb 58 R/W
Type AL6 (0=serious;1=min.1;2=min.2) Pb 59 R/W
Type AL7 (0=serious;1=min.1;2=min.2) Pb 60 R/W
61 R/W
