Carel pCO1 series User Manual

pCO Sistema
Code: +030220336 - rel. 1.5 - 22/12/10
20
2.6 pCO
xs
technical specifications
• pCO
pCOpCO
pCO
XS
XSXS
XS
ana
anaana
analogue inputs
logue inputslogue inputs
logue inputs
Analogue conversion 10-bit A/D converter embedded in CPU
Maximum number 4
Type Universal: 2 (inputs B1, B2)
-CAREL NTC (-50T90°C; R/T 10kΩ±1% at 25°C)
-Voltage 0 to 1 Vdc, 0 to 5 Vdc ratiometric;
-Current 0 to 20 mA or 4 to 20 mA. Input resistance: 100Ω
Can be selected via software
Universal: 2 (inputs B3, B4)
-CAREL NTC (-50T90°C; R/T 10kΩ±1% at 25°C)
-Voltage 0 to 5 Vdc ratiometric
Can be selected via software
Time constant for each input 1 s
Input precision NTC ± 0.5°C
Input precision 0-1V ± 3 mV
Input precision 0-5V ± 15 mV
Input precision 0-20 mA ± 0.06 mA
Warning:
Warning:Warning:
Warning: for the power supply of any active probes, the 24 Vdc available at the +Vdc terminal (J2) can be used. The maximum current is 80 mA, protected against
short-circuits. To supply the 0/5V ratiometric probes, use the 5V available at the +5Vref (terminal J2). The maximum current is 60 mA.
• pCO
pCOpCO
pCO
XS
XSXS
XS
digital inputs
digital inputsdigital inputs
digital inputs
Type Not optically-isolated with voltage-free contact
Maximum number
no. optically-isolated inputs at 24 Vac 50/60 Hz
or 24Vdc
no. optically-isolated inputs at 24 Vac/Vdc or 230
Vac 50/60 Hz
Total
6 None 6
Minimum digital input pulse detection time
Normally open (open-closed-open) 150 ms
Normally closed (closed-open-closed) 400 ms
Power supply to the inputs internal
• pCO
pCOpCO
pCO
XS
XSXS
XS
analogue outputs
analogue outputsanalogue outputs
analogue outputs
Type Not optically-isolated
Maximum number 2 outputs (Y1 and Y2), 0 to 10 Vdc and
1 output (Y3), PWM with 5V pulse of programmable duration
Power supply internal
Precision outputs Y1-Y2 ± 3% of full scale
Resolution 8 bit
Settling time outputs Y1-Y2 2s
Maximum load
1 k
Ω
(10 mA) for 0 to 10 Vdc and 470
Ω
(10 mA) for PWM
Note:
Note:Note:
Note: the synchronicity for the PWM output derives from the SYNC and G0 inputs. The PWM output (Y3) can become a pulse modulation output (duration of the
pulse proportional to the analogue value) by setting the software. The PWM may be in synchronicity with the SYNC signal or have a fixed cycle duration of 2 ms.
• pCO
pCOpCO
pCO
XS
XSXS
XS
digital outputs
digital outputsdigital outputs
digital outputs
Insulation distance
The relay outputs have different features depending on the model of PCO
XS
.
The outputs can be divided into groups. There is double insulation between the groups (cells in the table) and consequently these may have
different voltages. There is also double insulation between each terminal of the digital outputs and the rest of the controller. The relays
belonging to the same group (individual cells in the table) have basic insulation and therefore can have the same power supply (24 Vac or 230
Vac).
Makeup of the
groups
Version Reference of the relays with the same insulation
Group 1 Group 2 Group 3
- 1 to 3 4 5
Type of relay Type A Type A Type A
Number of
changeover contacts
1: output 5
Switchable power Relay type A
Relay ratings SPDT, 2000 VA, 250 Vac, 8 A resistive
pCO
xs
approval
UL873 2.5 A resistive, 2 A FLA, 12 A LRA, 250 Vac, (30,000 cycles)
EN 60730-1 2 A resistive, 2 A inductive, cos
ϕ
=0.6, 2(2)A (100,000 cycles)
Maximum number
of SSR outputs
2: outputs 4 and 5;
Electrical specifications: working voltage 24 Vac/Vdc, maximum switchable output 10 Watts
Warnings:
Warnings:Warnings:
Warnings:
• the groups that the digital outputs are divided into have two common pole terminals to simplify wiring.
• Make sure that the current running through the common terminals does not exceed the rated current of an individual terminal, that is, 8 A.
