Carel pCO1 series User Manual

Devices that can be connected to the pCO1 128KB
serial 1 - BMS serial 2 - FieldBus
Device
connector J11 connector J10 PCO1004850 PCOS004850 PCO100MDM0 PCO10000F0 PCO10000R0 PCO100CLP0 PCO1000WB0 PCO1000BA0 PCOS00HBB0 PCO100FD10 PCOS00FD20 PCO100TLN0 PCO100MPB0 PCOS00HBF0
Protocol active on the pCO Notes
PST terminal X PST terminal Incompatible with tLAN Master 5 expansions
PLD terminal X
pCOT - pCOI terminal X Local terminal or pLAN
pGD0 - pGD1 terminal X Local terminal or pLAN With Local terminal the pGD* works in pCOT emulation mode
pGD2 - pGD3 terminal X Local terminal or pLAN
Aria terminal X
pCO in pLAN X pLAN
FCM series controllers X
EVD200 X
EVD400 X X
pLAN or CAREL Master or
CAREL Master 5 exp.
Can only be activated on one serial port. CAREL Master 5 exp.:
incompatible with PST terminal
CAREL Slave devices (tLAN) X
CAREL Master or CAREL
Master 5 exp.
Can only be activated on one serial port. CAREL Master 5 exp.:
incompatible with PST terminal
CAREL Slave devices (RS485) X X X X
CAREL Master or
CAREL Master: can only be activated on one port, BMS serial or FieldBus
serial.
pCOexp 485 X X X X
CAREL Master 5 exp.
CAREL Master 5 exp.: can only be activated on one port, pLAN serial or
FieldBus serial
pCOexp tLAN X CAREL Master 5 exp.
Can only be activated on one port, pLAN serial or FieldBus serial
μChiller2 expansion X
Hydronic fan coil and CANbus X X CAREL Master
Can only be activated on one port, BMS serial or FieldBus serial
PlantVisor local X X X X
PlantWatch X X X X
PCGate X X X X
WebGate X X X X Can only be activated on one serial port
GATEWAY**0 X X X X
LON - Echelon RS485 X Incompatible with protocols
LON - Echelon FTT10 X CAREL Slave PSTN
TREND X GSM
HTTP client X Modbus Slave
BACnet/Ethernet X
BACnet/IP X
BACnet/MSTP (RS485) X
SNMP v1, SNMP v2C X
SNMP v3 X For SNMP v3 special pCOWEB software is used
Modbus supervisor (RTU) X X X X Modbus Slave
Incompatible with CAREL Slave, PSTN, GSM
Modbus Slave devices X X X X Modbus Master Can only be activated on one serial port
pCOexp Modbus X X X X
BenShaw devices X X Modbus Master - Benshaw Maximum of two Benshaw devices
WinLoad local XXXX XX WinLoad
Can only be activated on 1 serial. Incompatible with PSTN & GSM; on
FieldBus serial from Bios 4.00
WinLoad remote, analogue modem X PSTN Incompatible with CAREL Slave and Modbus Slave
PlantVisor remote, analogue modem X
WinLoad remote, GSM modem X
PlantVisor remote, GSM modem X GSM Incompatible with CAREL Slave and Modbus Slave
Send and receive SMS X
Belimo devices (max 8) X MP-Bus
Serial printer X X Serial printer
Can only be activated on one port, BMS serial or FieldBus serial
72
serial 0 -
pLAN
