NOTE: When putting your gate away you can remove the gate panels without removing the wall
mounting brackets.
STEP 8
To remove your gate, rotate
all wall mounting brackets to
the unlocked position. You
are now able to detach the
gate connectors from the wall
mounting brackets.
NOTE: This gate is designed to fit minimum width openings 36 inches wide to maximum width
openings 192 inches wide.
36 INCHES
