Carlson 2360 - Installing Your Gate as a Freestanding Enclosure

ENGLISH
8
Option B: Installing Your Gate as a Freestanding Enclosure
STEP 1
Unfold the gate frame at each pivoting
joint by loosening each cap.
STEP 2
Position the pet pen into your desired configuration, then join the free ends of the pet pen
together at the plastic joints.
