Know your air conditioner
1. Control panel
2. Cooling air outlet
3. Air inlet
4. Air filter
5. Water tank
6. Exhaust air outlet
7. Castors
8. Exhaust hose
9. Adaptors for insertion over
hose and into back of air
condiitioner
10. Round, window connector
11. Foam strips for filling
open window space
12. Adaptor for insertion
over hose & into foam
strip/window
i
Information
Please read these instructions before using your air conditioner.
