Carpenter MFG CP635 - Clearing a Jammed Nail; Maintenance

1514
Model No. CP635 contact us 1-888-666-1887
OPERATING INSTRUCTIONS
MAINTENANCECLEARING A JAMMED NAIL
1.Disconnect air hose.
2.Remove the nose cap
3.Disassemble the two hexagon screws
4.Remove the cover plate and remove the pins
5.Assembly the cover plate and tighten the screws
6.Assembly the nose cap
MAINTENANCE
Nose
Nose Cap
Screw
(M4x8)
