CARPENTER CCN65Z - TROUBLESHOOTING; Operator troubleshooting

2726
Maintenance chart
ACTION
Drain air line filter daily.
Keep lubricator filled.
Clean filter element-then blow air
through filter in direction opposite
to normal flow.
Clean magazine and feeder
mechanism.
Keep push lever working properly.
Lubricate the Nailer after nailing
Drain air compressor.
WHY
Prevent accumulation of
moisture and dirt.
Keep the Nailer lubricated.
Prevent clogging of filter
with dirt.
Prevent a jam
Promote operator safety and
efficient Nailer operation.
Extend the Nailer life.
Keep the Nailer operate
properly.
HOW
Open manual petcock.
Fill with lubricant.
Follow manufacturer’s
instructions.
Blow clean daily
Blow clean daily
Supply 2-3 drops of lubricant
into the nailer
Open petcock on air
compressor tank.
Operator troubleshooting
Most minor problems can be resolved quickly and easily using the table below.
If problems persist,contact a Carpenter for assistance.
PROBLEM
Nailer operates,but
no nail is driven
Weak drive.
Slow to cycle.
Drives too deep
Skipping nails.
Intermittent feed.
Nails jam
Driven nail is bent.
Drives properly
during normal
operation,but does
not drive fully at
faster nailing speeds.
POSSIBLE CAUSES
Check for a jam.
Check for proper nails.
Check air pressure.
---
Driver blade worn
Piston O-ring worn or damaged
Check air pressure.
Check for proper nails.
Check function of nail feeder per page
15.
---
Check position of nail holder
in manazine per page11.
Piston O-ring cut or heavily worn
Check for proper nails.
Driver blade worn
Check inside diameter of air hose.
SOLUTIONS
Clear a jam per page 22
Clean and lubricate.
Use only recommended nails.
Increase air pressure.(Do not
exceed 120 psi(8.3bar 8.5kg/cm2)
Use the lubricant.
Contact Carpenter for replacement.
Reduce air pressure.(Adjust 70-
120psi)
Use only recommended nails.
Clean and lubricate.
Use lubricant.
Adjust nail holder to proper
position.
Contact Carpenter for replacement.
Use only recommended nails.
Contact Carpenter for replacement.
Use larger air hose.
Model No. CCN65Z contact us 1-888-666-1887
TROUBLESHOOTING EXPLODED VIEW
Check function of feeder per page15.
