Thefollowingtablewillgiveyouanideaofwhatoperationtimeyoucanexpectwhenstartingfromafullychargedsystem:
  
Fluorescentlights,cellphones 4 30
Radios,fans,Depthnders 9 21
Camcorders.VCR’sspotlights 15 12
Electrictools,bilgepumps 24 7
Electric coolers 48 3
Aircompressors,carvacuums 80 1,5

Above15A,overloadprotectioncutsoffpowerfrom12Vlightersocket.Thiswillberestoredafteroneminutewhenapplianceisremovedfrom12Vlightersocket.
JuMp startIng
Foroptimumperformance,whenusingyourjumpstartertojumpstartavehicleorboat,pleasereadandfollowthesestep-by-stepinstructions:
1. Connectthered(+)‘alligator’clamptothered(+)positivebatteryterminalofthevehicleorboat.
2. Connecttheblack(-)‘alligator’clamptoanon-movingmetalpartoftheengine,NOTtothe(-)negativebatteryterminal.
3. Waitaminuteor2.
4. Switchthevehicleorboatengineignitionto‘start’fornomorethan5to6seconds.
5. Ifthevehicleorboatenginedoesnotstart,waitatleast3minutesbeforetryingagain.

1. Oncetheengineisrunning,disconnecttheblack(-)clamprstandreturnthecabletoitsstoredpositiononjumpstarter.
2. Disconnectthered(+)clampandreturnthiscabletoitsstoredpositiononthepowerbooster.
3. Assoonaspossible,connectyourjumpstartersystemtothe230VACadapter/chargerandrecharge.
coMpressor operatIon
Runcompressoronlyfor10minutesatatimecontinuously.Thenleaveofffor10minutesbeforeusingagain,sothatcompressorcancooloff.
1. Fortireinationusetheuniversaladapterthatisattachedpermanentlytotheairhose.Placethisadapter(no.C,seegure2),ontothetirevalve
system,presstheadapterleverdowntolockontothevalvesystem.
2. Forinationofleatherballs,otationdevices,etc.useoneoftheplasticnozzles.
3. Checkpressuregauge(No.A,seegure2),determinethedesiredpressure.
4. Turnthepowerswitch(NoB.seegure2).
5. Whenthedesiredpressureisreachedturnthecompressorswitch(No.B,seegure2)off.
6. Removetheadapter(No.C,seegure2)fromtireorotheritembeinginated.
12V DC Lead Acid Battery
Figure 3

Figure3showsabackviewofyourjumpstarterwiththecoverandeightscrewsremoved.Toreplacethebatteryfollowthesesteps.
1. Unscrewandremovetheeightcross-headedscrewsatthebackofyourjumpstarter.
2. Liftoffthecoverplatetoexposethebatterycompartment.
3. Unscrewthetwocross-headedscrewsatthetopofthebattery.
4. Liftthebatteryoutofthebatterycompartment.
