22
ly to joystick movements. Signal sounds
three times on switching over.
Headless Mode
13
c
The headless mode helps beginners
learn how to fly. Regardless of which di-
rection the Quadrocopter is rotated, the
flight direction always corresponds exactly
to the flight direction implemented on the
controller. Therefore a beginner no longer
has to steer mirror-imaged when he flies
e.g. to himself.
If you press the “Headless Mode Button”
9
, an acoustic signal sounds for as long as
you are in the Headless mode. To de-
activate the Headless mode, press the
button renewed.
Trimming the Quadrocopter
14
Auto-trimming
1.
Place the Quadrocopter on a hori-
zontal surface.
2.
Link the Quadrocopter with the con-
troller as described in “Linking the
model with the controller”.
3.
Slide the gas lever and the lever for
forward
/
back simultaneously into
the right lower corner. The LED on the
Quadrocopter flashes on briefly and
then lights up continuously. The signal-
ling tone will sound once.
4.
The neutral setting is completed.
15
When hovering, if the Quadrocopter flies to
the left or right without you moving the lever
for left / right movement, please proceed as
follows:
If the Quadrocopter moves on its own fast
or slow sideways to the left, press the low-
er right trimmer for right / left tilt in steps to
the right. If the Quadrocopter moves right,
press the trimmer for right / left tilt in steps
to the left.
16
When hovering, if the Quadrocopter flies
forwards or backwards without you mov-
ing the lever for forwards or backwards
movement, please proceed as follows:
If the Quadrocopter moves on its own fast
or slow forwards, press the upper right
trimmer for forwards / backwards in steps
downwards. If the Quadrocopter moves
backwards, press the trimmer for forwards /
backwards in steps upwards.
17
When hovering and without you moving the
lever for circling on the spot, if the quadro-
copter rotates to left or right, proceed as
follows: If the Quadrocopter rotates quickly
or slowly to the left around its own axis,
press the trimmer for rotation below left in
steps to the right. If the Quadrocopter ro-
tates to the right, press the trimmer for rota-
tion in steps to the left.
Changing the rotor blades
18
Use a smooth narrow object to help draw
off a rotor blade if necessary. Make sure
that you draw the rotor blade with great
care vertically upwards, and hold the mo-
tor from below to stabilise it.
19
QR code for motor-change system,
spare parts and further information.
20
WARNING!
Be sure to note the marking and colour,
also the tilt angle of the rotor blades!
Front left: red marking “B”
Front right: red marking A
Rear right: black marking B”
Rear left: black marking A”
Problem: Remote control does not work.
Cause: The ON/OFF-power switch is turned
“OFF”.
Solution: Turn the ON/OFF-power switch ON.
Cause: The batteries have been wrongly
inserted.
Solution: Check if the batteries have been
correctly inserted.
ENGLISH
Troubleshooting
