13
15 206 449 Load Loss
If this fault appears, there may be a prob-
lem with software configuration.
To reset the processor, cycle power to chiller,
check VFD_CONF settings and save settings
when exiting VFD_CONF (PIC3)/CFGUMVFD
(PIC6) configuration screen.
Check VFD parameters with Drive Explorer.
17 216 446
The DC bus ripple
has exceeded a
preset level.
Line Voltage imbalance
Check phase-to-phase and phase-to-ground dis-
tribution bus voltage. Increase Line Voltage %
Imbalance in VFD_CONF (PIC3)/CFGUMVFD
(PIC6) screen.
20 206 449 TorqPrv Spd Band See VFD Fault Code 15 See VFD Fault Code 15
21 225 445 Output PhaseLoss
The current in one or more phases has
been lost or remains below a preset level.
Check Motor Current % Imbalance in VFD_CONF
(PIC3)/CFGUMVFD (PIC6) screen.
24 204 442 Decel Inhibit
The drive is not following a commanded
deceleration because it is attempting to
limit bus voltage.
Verify input voltage is within drive specified
limits.
Verify system ground impedance follows proper
grounding techniques.
Disable bus regulation P186 and/or add dynamic
brake resistor and/or extend deceleration time
P537 and P538.
33 206 449 AuRsts Exhausted See VFD Fault Code 15 See VFD Fault Code 15
36 286 438 SW Overcurrent
The drive output current has exceeded
the 1 ms current rating.
Check for excess load, improper DC boost set-
ting, DC brake volts set too high.
38
220 432
Phase U to Gnd
GROUND FAULT
Check wiring between drive and motor.
Check motor for grounded phase.
Check motor terminals.
Replace drive.
39 Phase V to Gnd
40 Phase W to Gnd
41
220 449
Phase UV Short
GROUND FAULT
Check wiring between drive and motor.
Check motor terminals.
Replace drive.
42 Phase VW Short
43 Phase WU Short
44 206 432
Phase UNot
GROUND FAULT (no LF2 equivalent)
Check wiring between drive and motor.
Check motor terminals.
Replace drive.
45 206 432
Phase VNot
46 206 432
Phase WNot
55 NONE 444
Ctrl Bd Inverter
Overtemp
The temperature sensor on the main con-
trol board detected excessive heat.
Check that VFD refrigerant isolation valves are
open. Check VFD refrigerant strainer.
61 206 449 Shear Pin 1 See VFD Fault Code 15 See VFD Fault Code 15
62 206 449 Shear Pin 2 See VFD Fault Code 15 See VFD Fault Code 15
64 206 449 Drive Overload Drive is overloaded.
Check for high entering water temperature or low
condenser water flow. Check current settings in
VFD_CONF (PIC3)/CFGUMVFD (PIC6) screen.
77 206 449 IR Volts Range See VFD Fault Code 15 See VFD Fault Code 15
78 206 449
FluxAmpsRef
Rang
See VFD Fault Code 15 See VFD Fault Code 15
79 206 449 Excessive Load
Motor did not come up to speed in the
allotted time.
Check that guide vanes are closed completely.
Check for high entering water temperature or low
condenser flow.
Repeat Autotune
80 206 449 AutoTune Aborted See VFD Fault Code 15 See VFD Fault Code 15
87 206 449 IXo VoltageRange
Ixo voltage calculated from motor name-
plate data is too high.
Re-enter motor nameplate data in VFD_CONF
(PIC3)/CFGUMVFD (PIC6) screen.
91 206 449 Pri VelFdbk Loss See VFD Fault Code 15 See VFD Fault Code 15
93 206 449 HW Enable Check See VFD Fault Code 15 See VFD Fault Code 15
94 206 449 Alt VelFdbk Loss See VFD Fault Code 15 See VFD Fault Code 15
95 206 449 Aux VelFdbk Loss See VFD Fault Code 15 See VFD Fault Code 15
96 206 449 PositionFdbkLoss See VFD Fault Code 15 See VFD Fault Code 15
97 206 449 Auto Tach Switch See VFD Fault Code 15 See VFD Fault Code 15
100 206 451
Parameter
Chksum
The checksum read from the board does
not match the checksum calculated.
Press ICVC reset (PIC3)/Reset alarm (PIC6).
Check VFD_CONF parameters.
Cycle power to the drive.
106 284 453 Incompat MCB-PB
The main control board did not recognize
the power structure.
Flash with newer Application version software.
107 NONE 451 Replaced MCB-PB
The main control board was moved to a
different power structure. Data set to
default values.
Press ICVC reset (PIC3)/Reset alarm (PIC6).
Check VFD_CONF (PIC3)/CFGUMVFD (PIC6)
parameters.
Cycle power to the drive.
113 206 451 Tracking DataErr Internal data error
Press ICVC reset (PIC3)/Reset alarm (PIC6).
Cycle power to the drive.
124 206 451 App ID Changed Application firmware changed. Verify application version.
Table 5 — Powerflex 755 Fault Code Descriptions and Corrective Actions (cont)
VFD
FAULT
CODE
ON VFD
HIST
SCREEN
ICVC
FAULT
STATE
PIC6
FAULT
STATE
FAULT TYPE DESCRIPTION CORRECTIVE ACTION

Carrier 19XRV Series Specifications

General

Frequency	50/60 Hz
Motor Type	Hermetic
Type	Water-Cooled, Centrifugal
Compressor Type	Centrifugal
Refrigerant	R-134a
