6
ACCESSORIES
ORDER NUMBER
DESCRIPTION 24--- 31 36 --- 31 48--- 31 60 --- 30
KAACH1701AAA CRANKCASE HTR X X S S
KSAHS2501* HARD START KIT X X
KSAHS2801* HARD START KIT X
KSAHS2601 HARD START KIT X
KSASH2301COP SOUND BLANKET X X
KSASH2401COP SOUND BLANKET X X
KAALS0201LLS SOLENOID VAL VE KIT X X X X
KSASF0101AAA SUPPORT FEET X X X X
X = Accessory S= Standard
* Not backward compatible to previous series.
ACCESSORY USAGE GUIDELI NE
ACCESSORY
REQUIRED FOR LONG LINE
APPLICATIONS*
REQUIRED FOR
SEA COAST
APPLICATIONS
(Within 2 miles/3.22 km)
Compressor Start Assist Capacitor and Relay Ye s No
Crankcase Heater Ye s No
H a r d S h u t --- O f f T X V Ye s Ye s
Support Feet No Recommended
* For tubing l ine sets between 80 and 200 ft. (24.38 a nd 60.96 m) and/or 35 ft. (10.7 m) ver tical differential, refer to Residential Split---System Longline
Application Guideline.
Accessory Description and Usage (Listed Alphabetically)
1. Compr essor Start Assist -- Capacitor and Relay
Start capacitor and relay gives a ”hard” boost to compressor
motor at each start up.
Usage Guideline:
Required for 2 -- stage non--communicating units in the
following applications:
Long line
Suggested for all compressors in areas with a history of
low voltage problems.
2. Crankcase Heater
An electric resistance heater which mounts to the base of the
compressor to keep the lubricant warm during off cycles.
Improves compressor lubrication on restart and minimizes the
chance of liquid slugging.
Usage Guideline:
Required in low ambient cooling applications.
Required in long line applications.
Suggested in all commercial applications.
3. Outdoor Air Temperature Sensor
Designed for use with Carrier Thermostats listed in this
publication. This device enables the thermostat to display the
outdoor temperature. This device also
is required to enable special thermostat features such as auxiliary
heat lock out.
Usage Guideline:
Suggested for all Carrier thermostats listed in this
publication.
4. Support Feet
Four stick -- on plastic feet that raise the unit 4 in. (101.6 mm)
above the mounting pad. This allows sand, dirt, and other debris
to be flushed from the unit base, minimizing corrosion.
Usage Guideline:
Suggested in the following applications:
Coastal installations.
Windy areas or where debris is normally circulating.
Rooftop installations.
For improved sound ratings.
5. Thermostatic Expansion Valve (TXV)
A modulating flow--control valve which meters refrigerant liquid
flow rate into the evaporator in response to the superheat of the
refrigerant gas leaving the evaporator.
Kit includes valve, adapter tubes, and external equalizer tube.
Hard shut off types are available.
NOTE: When using a hard shut off TXV with single phase
reciprocating compressors, a Compressor Start Assist Capacitor
and Relay is required.
Usage Guideline:
Required to achieve AHRI ratings in certain equipment
combinations. Refer to combination ratings.
Hard shut off TXV or LLS required in air conditioner
long line applications.
Required for use on all zoning systems.
24ACB7
