Overview of Wall-mounted User Interface
General description
The Wall-Mounted User Interface (WUI) is compatible only with the NHC controller for Heat pump or Cooling only
units.
Read the WUI end-user manual for using it as a configuration interface.
Dimensions
Figure 1: WUI Control – side view and front view
15.4 mm
16 mm
90.1 mm
87.6 mm
0.5 mm
0.5 mm
