Accessories
* Use with low-ambient controller.
† Fan motor with ball bearings required.
‡ Requires outdoor thermostat.
* High-pressure switch must be added if not supplied with the system.
† Do not use in zoning heat pump applications.
ORDERING NUMBER DESCRIPTION
KAATD0101TDR
Time-Delay Relay — All Sizes
32LT660004† (RCD) MotorMaster® Control — Sizes 018, 024, 042-060
HC34GE232 (RCD) Ball Bearing Fan Motor — Size 018
HC38GE231 (RCD) Ball Bearing Fan Motor — Size 024–048
HC40GE232 (RCD) Ball Bearing Fan Motor — Size 060
KAAFT0101AAA* Evaporator Freeze Thermostat — All Sizes
KHAIR0101AAA* Isolation Relay — All Sizes
KSAHS1501AAA Compressor Start Assist — Capacitor/Relay — Sizes 018–042
KSAHS1701AAA Compressor Start Assist — Capacitor/Relay — Size 048
KSAHS1601AAA Compressor Start Assist — Capacitor/Relay — Size 060
KAACS0201PTC Compressor Start Assist — PTC — All Sizes
KAACH1401AAA Crankcase Heater — Size 018
KAACH1201AAA Crankcase Heater — Sizes 024–048
KSASH1801COP Sound Hood — Sizes 018–030
KSASH0601COP Sound Hood — Sizes 036, 042
KSASH2101COP Sound Hood — Sizes 048, 060
KHAOT0301FST Outdoor Thermostat — All Sizes
KHAOT0201SEC Secondary Outdoor Thermostat — All Sizes
KHAIC0101AAA‡ Interface Control (Optimizer II) — All Sizes
KSALA0201R22 Low Ambient Kit — All Sizes
KSATX0601HSO Thermostatic Expansion Valve (Hard Shutoff) — Sizes 018–042
KSATX0701HSO Thermostatic Expansion Valve (Hard Shutoff) — Sizes 048–060
Standard Low-Pressure Switch — All Sizes
KHAHI0101HPS High-Pressure Switch — All Sizes
P504-8083S (RCD) Filter Drier (Bi-flow) — Sizes 018–036
P504-8163S (RCD) Filter Drier (Bi-flow) — Sizes 042–060
KHALS0401LLS Liquid Solenoid Valve (LSV) — All Sizes
KSACG1204CSM Inlet Grille Kit (4 Pack) — Size 018
KSACG1704CMD Inlet Grille Kit (4 Pack) — Size 024
KSACG1804CMD Inlet Grille Kit (4 Pack) — Size 042
KSACG2004CMD Inlet Grille Kit (4 Pack) — Sizes 030, 036, 048
KSACG2304CMD Inlet Grille Kit (4 Pack) — Size 060
KAACF1001MED Coastal Filter Kit — Size 018
KAACF1101LRG Coastal Filter Kit — Sizes 024–060
THERMOSTAT PKG DESCRIPTION
TSTATCCNHP01-B
Thermostat, Auto Changeover, Non-Programmable, °F /°C, 2-Stage Heat, 1-Stage Cool
TSTATCCPHP01-B Thermostat, Auto Changeover, 7-Day Programmable, °F /°C, 2-Stage Heat, 1-Stage Cool
TSTATCCPDF01-B*
Thermostat, Auto Changeover, 7-Day Programmable, °F/°C, Dual Fuel Thermostat,
Must be used with Outdoor Sensor (TSTATXXSEN01-B) Included
TSTATCCBHP01-B Builder’s Thermostat, Manual Changeover, Non-Programmable, °F, 2-Stage Heat, 1-Stage Cool
TSTATCCSHP01
Standard Programmable Thermostat — Manual Changeover, 5-2 Day Programmable, °F/°C, 1-Stage
Heat, 1-Stage Cool
TSTATCCPRH01-B†
Thermidistat™ Control — Non-Programmable/Programmable Thermostat with Humidity Control (For
use in Dual Fuel, AC, HP, and 2S applications. Includes Outdoor Air Temperature Sensor.)
TSTATXXSEN01-B Outdoor Air Temperature Sensor
TSTATXXNBP01 Backplate for Non-Programmable Thermostat
TSTATXXPBP01 Backplate for Programmable Thermostat and Thermidistat Control
TSTATXXBBP01 Backplate for Builder’s Thermostat
TSTATXXSBP01 Backplate for Standard Programmable Thermostat
TSTATXXCNV01 Thermostat Conversion Kit (4 to 5 Wire) — 10 Pack
