Carrier 40MBQB18D--3 Service Manual

7
DIMENSIONS -- OUTDOOR
Table 5—Outdoor
Unit Size 18 27 36 48
Height in (mm) 27.56(700) 31.89(810) 31.89(810) 36.93(1369)
Width in (mm) 33.27(845) 37.20(945) 37.20(945) 53.9(938)
Depth in (mm) 12.60(320) 15.55(395) 15.55(395) 15.43(392)
Weight -- Net lbs (kg) 114.63(52) 154.76(70.2) 169.75(77) 255.50(115.9)
Fig. 2 – Outdoor Dimensions Size 18
