TXV #1
TXV #2
Compressor #1
Muffler
Compressor #1
Muffler
HPS & LPS mounted on
compressor
HPS & LPS mounted on
compressor
HPS- HK02ZA428
Cut-In - 320 PSI
Cut-out - 420 PSI
LPS - HK02ZB027
Cut -In - 22 PSI
Cut-out - 7 PSI
LEGEND
Fig. 85 — Typical Refrigerant Circuiting (48AJ,AK,AW,AY027,030)
FPS — Freeze Protection Switch
HPS — High-Pressure Switch
LPS — Low-Pressure Switch
TXV — Thermostatic Expansion Valve
