Carrier 48PG24 - Page 26

26
Table 22 — Fan Performance — 48PGE28 — Horizontal Supply and Return Units
LEGEND
Boldface indicates field-supplied motor/drive required.
NOTES:
1. Motor drive ranges:
(E) Low Range: 687-873, 5.75 Bhp
(F) Mid-Low Range: 805-1007, 5.75 Bhp
(G) Mid-High Range: 941-1176, 8.63 Bhp
(H) High Range: 1014-1297, 11.50 Bhp
All other rpms require field-supplied motor or drive.
2. See page 30 for general fan performance notes.
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
6,500 799 3.14 833 3.35 872 3.61 914 3.90 958 4.24
7,000 856 3.79 887 4.00 921 4.25 958 4.54 999 4.87
7,500 913 4.52 941 4.74 972 4.99 1006 5.27 1042 5.59
8,000 971 5.33 996 5.55 1024 5.80 1055 6.08 1088 6.40
8,500 1029 6.24 1052 6.46 1078 6.71 1106 6.99 1136 7.30
9,000 1087 7.23 1108 7.46 1132 7.71 1158 7.99 1185 8.29
9,500 1145 8.32 1165 8.55 1187 8.80 1211 9.08 1236 9.39
10,000 1203 9.50 1222 9.74 1243 10.00 1265 10.28 1288 10.58
10,500 1261 10.79 1279 11.03 1299 11.29 1319 11.58 1341 11.88
11,000 1320 12.18 1337 12.43 1355 12.70 1374 12.98 1394 13.28
11,500 1378 13.68 ————————
12,000 ——————————
12,500 ——————————
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
6,500 1005 4.62 1052 5.05 1100 5.51 1148 6.00 1195 6.52
7,000 1041 5.24 1084 5.64 1128 6.09 1172 6.57 1217 7.08
7,500 1080 5.94 1119 6.33 1160 6.76 1201 7.22 1242 7.71
8,000 1122 6.74 1158 7.12 1195 7.53 1233 7.97 1272 8.45
8,500 1167 7.63 1200 8.00 1234 8.40 1269 8.83 1304 9.29
9,000 1214 8.63 1244 8.99 1275 9.37 1308 9.79 1340 10.23
9,500 1262 9.72 1290 10.07 1319 10.45 1349 10.85 1379 11.28
10,000 1312 10.91 1338 11.25 1365 11.63 1392 12.02 ——
10,500 1363 12.20 1387 12.55 ——————
11,000 ——————————
11,500 ——————————
12,000 ——————————
12,500 ——————————
Bhp — Brake Horsepower Input to Fan
H
H
H
H
H
E
E
E
F
F
F
F
F
G
G
G
G
G
H
H
H
H
H
F
G
G
G
G
