Carrier EDGE Pro - Page 20

20
Rc
Rh
W1
G
Y2
C
O/W2/B
Y1
OAT
RRS
SRTN
HUM
D1
D2
V+
Vg
COMMERCIAL THERMOSTAT
COMPLETE C
P1
Y
W
O
G
R
C
AL1
FIRST
COMPRESSOR
a33-9285
Fig. 26 — Thermostat Wiring — 50HQL, KQE, KQL, P1, PC, PEC, PS, PSW, PT, RHC, RHE, RHR, RHS, RTG,
RVC, RVE, RVR, RVS, RWS,VQL Water Source Heat Pump Units with Complete C Controls
Rc
Rh
W1
G
Y2
C
O/W2/B
Y1
OAT
RRS
SRTN
HUM
D1
D2
V+
Vg
COMMERCIAL THERMOSTAT
COMPLETE C
P1
Y
W
O
G
R
C
AL1
COMPLETE C
P1
SECOND
COMPRESSOR
Y
FIRST
COMPRESSOR
G
R
QT
C
W1
W2
W3
W4
INSTALL JUMPER G TO QT
DUCT HEATER
a33-9284
Fig. 27 — Thermostat Wiring — 50HQL, KQE, KQL, P1, PC, PEC, PS, PSW, PT, RHC, RHE,
RHR, RHS, RTG, RVC, RVE, RVR, RVS, RWS, VQL Water Source Heat Pump Units with
Complete C Controls and Duct Heating Option
