Carrier ESTRELLA - Optional Drain Pan; Chassis Re-insertion; Chassis Locking; Front Grille Attachment

22
This optional drain pan is
needed if condensate is to be
discharged completely and is
available through service.
Slide the chassis back into the
outer wrapper.
Lock the chassis to the outer
wrapper reusing the screw.
Attach the front grille to the
outer wrapper
5.
6.
7.
8.
5
6
7
8
