Table 6 – Maximum Allowable Exposed Vent Pipe Length (Ft / M) with Insulation in
Winter Design Temperature Ambient*
UNIT SIZE
WINTER DESIGN MAXIMUM PIPE
INSULATION THICKNESS†
WINTER
DESIGN
TEMPERATURE
MAXIMUM
PIPE
DIAMETER (IN.) 0 3/8 1/2 3/4 1
042060
20_F/--6.7_C 2 30 / 9.1 55 / 16.8 61 / 18.6 70 / 21.3 70 / 21.3
0_F / --17.8_C 2 16 / 4.9 33 / 10.1 38 / 11.6 46 / 14.0 53 / 16.2
-- 2 0 _F / --28.9_C 2 9/2.7 23 / 7.0 26 / 7.9 33 / 10.1 38 / 11.6
042080
060080
20_F/--6.7_C 2 37 / 11.2 65 / 19.8 70 / 21.4 70 / 21.3 70 / 21.3
0_F / --17.8_C 2 20 / 6.1 39 / 11.9 45 / 13.7 55 / 16.8 63 / 19.2
-- 2 0 _F / --28.9_C 2 11 / 3.4 27 / 8.3 31 / 9.4 39 / 11.9 45 / 13.7
060100
20_F/--6.7_C 2--1/2 41 / 12.5 70 / 21.3 70 / 21.3 70 / 21.3 70 / 21.3
0_F / --17.8_C 2--1/2 21 / 6.4 42 / 12.8 48 / 14.6 59 / 18.0 68 / 20.7
-- 2 0 _F / --28.9_C 2--1/2 11 / 3.4 28 / 8.5 33 / 10.1 41 / 12.5 49 / 14.9
060120
20_F/--6.7_C 3 49 / 14.9 70 / 21.3 70 / 21.3 70 / 21.3 70 / 21.3
0_F / --17.8_C 3 26 / 7.9 51 / 15.5 58 / 17.7 70 / 21.3 70 /21.3
-- 2 0 _F / --28.9_C 3 15 / 4.6 35 / 10.7 40 / 12.2 50 / 15.2 59 / 18.0
* Pipe length (ft/m) specified for maximum pipe lengths located in uncondition ed spaces. Pipes located in un conditioned space cannot exceed total allowable
pipe length as specified in Table ?.
†Insulation thickness based on R valu e of 3.5 per in.
58MVC

Carrier INFINITY ICS 58MVC Specifications

Power

electrical supply voltage	115 volts
electrical supply frequency	60 Hz
electrical supply phase	single-phase

Operating Environment

fuel gas efficiency	92.1 to 95% AFUE
minimum air delivery	_ _ _ cfm
external static pressure	0.50 in. wc

Weight and Dimensions

casing thickness	0.030 in
depth	_ in.
width	_ in.
height	_ in.
