Detailed cooling capacities* continued
See notes on pg. 38.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38TXA024-34 Outdoor Section With CC5A/CD5AA030 Indoor Section continued
700
57 21.18 21.18 1.55 20.24 20.24 1.75 19.29 19.29 1.98 18.25 18.25 2.22 17.12 17.12 2.47 15.93 15.93 2.75
62 22.64 20.05 1.55 21.22 19.43 1.77 19.94 18.79 1.99 18.56 18.06 2.22 17.12 17.12 2.47 15.93 15.93 2.75
67 24.77 16.75 1.56 23.85 16.60 1.78 22.47 16.09 2.02 21.00 15.48 2.28 19.45 14.85 2.53 17.78 14.18 2.81
72 25.81 13.18 1.58 25.61 13.23 1.79 24.84 13.05 2.03 23.58 12.61 2.29 22.06 12.07 2.57 20.37 11.46 2.87
800
57 22.22 22.22 1.58 21.17 21.17 1.80 20.15 20.15 2.03 19.06 19.06 2.27 17.91 17.91 2.53 16.64 16.64 2.81
62 23.20 21.31 1.59 21.76 20.74 1.81 20.42 20.01 2.03 19.06 19.06 2.27 17.91 17.91 2.53 16.64 16.64 2.81
67 25.02 17.33 1.60 24.32 17.46 1.81 23.00 17.09 2.05 21.46 16.52 2.32 19.85 15.87 2.58 18.15 15.19 2.86
72 25.88 13.37 1.62 25.75 13.52 1.83 25.15 13.50 2.07 23.95 13.15 2.33 22.44 12.65 2.61 20.72 12.06 2.91
900
57 23.03 23.03 1.62 22.01 22.01 1.84 20.90 20.90 2.07 19.81 19.81 2.32 18.59 18.59 2.59 17.27 17.27 2.87
62 23.64 22.41 1.63 22.28 21.90 1.84 20.89 20.89 2.07 19.80 19.80 2.32 18.58 18.58 2.59 17.27 17.27 2.87
67 25.15 17.80 1.64 24.64 18.20 1.85 23.38 18.01 2.09 21.84 17.50 2.35 20.17 16.86 2.63 18.42 16.15 2.91
72 25.90 13.52 1.65 25.81 13.75 1.87 25.31 13.85 2.11 24.19 13.62 2.37 22.71 13.17 2.64 20.99 12.62 2.95
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
COILS + 58CV(A,X)155-22 VARIABLE SPEED FURNACE
CK5A/CK5BW 024 0.97 0.89
CE3AA 024 0.97 0.89 030 0.99 0.89
030 0.99 0.89 CK5PW 024 0.97 0.89
COILS + 58MVP040-14 VARIABLE SPEED FURNACE
030 0.99 0.90
CE3AA 024 0.97 0.90
COILS + 58MVP080-20 VARIABLE SPEED FURNACE
030 0.99 0.90 CC5A/CD5AW 024 0.97 0.89
COILS + 58MVP060-14 VARIABLE SPEED FURNACE
030 0.99 0.90
CC5A/CD5AA 024 0.97 0.90 CE3AA 024 0.97 0.89
030 0.99 0.90 030 0.99 0.90
CC5A/CD5AW 024 0.97 0.89 CK3BA 024 0.97 0.88
030 0.99 0.90 030 0.99 0.89
CE3AA 024 0.97 0.89 CK5A/CK5BW 024 0.97 0.88
030 0.99 0.90 030 0.99 0.89
CK3BA 024 0.97 0.87 CK5PW 024 0.97 0.89
030 0.99 0.89 030 0.99 0.90
CK5A/CK5BA 024 0.97 0.89
COILS + 58MVP100-20 VARIABLE SPEED FURNACE
030 0.99 0.90 CC5A/CD5AW 024 0.97 0.89
CK5A/CK5BW 024 0.97 0.88 030 0.99 0.90
030 0.99 0.89 CE3AA 024 0.97 0.89
CK5PA 024 0.97 0.89 030 0.99 0.89
030 0.99 0.90 CK3BA 024 0.97 0.87
CK5PW 024 0.97 0.89 030 0.99 0.89
030 0.99 0.90 CK5A/CK5BW 024 0.97 0.88
COILS + 58MVP080-14 VARIABLE SPEED FURNACE
030 0.99 0.89
CC5A/CD5AW 024 0.97 0.90 CK5PW 024 0.97 0.89
030 0.99 0.90 030 0.99 0.90
CE3AA 024 0.97 0.90
COILS + 58MVP120-20 VARIABLE SPEED FURNACE
030 0.99 0.90 CE3AA 024 0.97 0.90
CK3BA 024 0.97 0.88 030 0.99 0.90
030 0.99 0.89 — — —
