Carrier Performance 13 38TXA User Manual

23
Detailed cooling capacities*
See notes on pg. 38.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38TXA024-34 Outdoor Section With CC5A/CD5AA030 Indoor Section
700
57 21.18 21.18 1.55 20.24 20.24 1.75 19.29 19.29 1.98 18.25 18.25 2.22 17.12 17.12 2.47 15.93 15.93 2.75
62 22.64 20.05 1.55 21.22 19.43 1.77 19.94 18.79 1.99 18.56 18.06 2.22 17.12 17.12 2.47 15.93 15.93 2.75
67 24.77 16.75 1.56 23.85 16.60 1.78 22.47 16.09 2.02 21.00 15.48 2.28 19.45 14.85 2.53 17.78 14.18 2.81
72 25.81 13.18 1.58 25.61 13.23 1.79 24.84 13.05 2.03 23.58 12.61 2.29 22.06 12.07 2.57 20.37 11.46 2.87
800
57 22.22 22.22 1.58 21.17 21.17 1.80 20.15 20.15 2.03 19.06 19.06 2.27 17.91 17.91 2.53 16.64 16.64 2.81
62 23.20 21.31 1.59 21.76 20.74 1.81 20.42 20.01 2.03 19.06 19.06 2.27 17.91 17.91 2.53 16.64 16.64 2.81
67 25.02 17.33 1.60 24.32 17.46 1.81 23.00 17.09 2.05 21.46 16.52 2.32 19.85 15.87 2.58 18.15 15.19 2.86
72 25.88 13.37 1.62 25.75 13.52 1.83 25.15 13.50 2.07 23.95 13.15 2.33 22.44 12.65 2.61 20.72 12.06 2.91
900
57 23.03 23.03 1.62 22.01 22.01 1.84 20.90 20.90 2.07 19.81 19.81 2.32 18.59 18.59 2.59 17.27 17.27 2.87
62 23.64 22.41 1.63 22.28 21.90 1.84 20.89 20.89 2.07 19.80 19.80 2.32 18.58 18.58 2.59 17.27 17.27 2.87
67 25.15 17.80 1.64 24.64 18.20 1.85 23.38 18.01 2.09 21.84 17.50 2.35 20.17 16.86 2.63 18.42 16.15 2.91
72 25.90 13.52 1.65 25.81 13.75 1.87 25.31 13.85 2.11 24.19 13.62 2.37 22.71 13.17 2.64 20.99 12.62 2.95
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 024 0.99 1.00 CK3BA 024 0.97 0.88
030 1.00 1.00 030 0.99 0.89
CC5A/CD5AW 024 0.99 1.00 CK5A/CK5BA 024 0.97 0.89
030 1.00 1.00 030 0.99 0.90
CE3AA 024 0.99 0.99 CK5A/CK5BW 024 0.97 0.89
030 1.00 0.99 030 0.99 0.89
CF5AA 024 0.99 1.00 CK5PA 024 0.97 0.89
CK3BA 024 0.99 0.99 030 0.99 0.90
030 1.00 0.99 CK5PW 024 0.97 0.89
CK5A/CK5BA 024 0.99 0.99 030 0.99 0.90
030 1.00 0.99
COILS + 58CV(A,X)090-16 VARIABLE SPEED FURNACE
CK5A/CK5BW 024 0.99 0.99 CC5A/CD5AA 024 0.97 0.89
030 1.00 0.99 030 0.99 0.89
CK5PA 024 0.99 0.99 CC5A/CD5AW 024 0.97 0.89
030 1.00 0.99 030 0.99 0.89
CK5PW 024 0.99 0.99 CE3AA 024 0.97 0.89
030 1.00 0.99 030 0.99 0.89
F(A,B)4BN(F,C) 024 1.00 0.99 CK3BA 024 0.97 0.87
030 1.02 1.00 030 0.99 0.88
FC4CNF 024 1.00 0.99 CK5A/CK5BA 024 0.97 0.88
030 1.02 0.99 030 0.99 0.89
FE4ANF 002 1.03 0.90 CK5A/CK5BW 024 0.97 0.88
003 1.03 0.89 030 0.99 0.89
FF1DNA 024 1.00 1.00 CK5PA 024 0.97 0.89
030 1.02 1.01 030 0.99 0.89
FF1DNE 024 1.00 1.00 CK5PW 024 0.97 0.88
030 1.02 1.01 030 0.99 0.89
FG3AAA 024 0.96 0.98
COILS + 58CV(A,X)110-20 VARIABLE SPEED FURNACE
FK4DNF 001 1.02 0.90 CC5A/CD5AW 024 0.97 0.89
002 1.03 0.90 030 0.99 0.90
003 1.03 0.89 CE3AA 024 0.97 0.90
FV4BNF 002 1.03 0.90 030 0.99 0.89
003 1.03 0.89 CK3BA 024 0.97 0.87
FX4BNF 030 1.02 0.98 030 0.99 0.89
COILS + 58CV(A,X)070-12 VARIABLE SPEED FURNACE
CK5A/CK5BW 024 0.97 0.89
CC5A/CD5AA 024 0.97 0.90 030 0.99 0.89
030 0.99 0.90 CK5PW 024 0.97 0.89
CC5A/CD5AW 024 0.97 0.90 030 0.99 0.90
030 0.99 0.90
COILS + 58CV(A,X)135-22 VARIABLE SPEED FURNACE
CE3AA 024 0.97 0.89 CE3AA 024 0.97 0.89
030 0.99 0.90 030 0.99 0.89
