Detailed cooling capacities* continued
See notes on pg. 38.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38TXA036-33 Outdoor Section With CC5A/CD5AA042 Indoor Section
1050
72 40.4 19.6 2.15 39.0 19.2 2.40 37.4 18.6 2.66 35.6 18.0 2.96 33.4 17.3 3.28 30.9 16.4 3.64
67 38.0 25.3 2.14 36.4 24.8 2.38 34.6 24.1 2.65 32.5 23.3 2.94 30.4 22.4 3.24 26.5 20.9 3.57
63†† 34.9 24.6 2.12 32.5 23.6 2.35 30.1 22.5 2.60 27.5 21.4 2.87 24.9 20.3 3.17 22.3 19.2 3.50
62 33.9 30.2 2.12 31.6 29.1 2.34 29.2 27.9 2.59 26.7 26.5 2.86 24.5 24.5 3.17 23.2 23.2 3.51
57 31.3 31.3 2.09 29.5 29.5 2.32 27.5 27.5 2.57 26.4 26.4 2.86 25.1 25.1 3.17 23.6 23.6 3.51
1200
72 41.0 20.3 2.20 39.7 19.9 2.45 38.1 19.4 2.72 36.2 18.9 3.02 33.9 18.1 3.34 31.4 17.3 3.70
67 38.5 26.5 2.19 37.0 26.1 2.43 35.0 25.3 2.69 33.1 24.7 2.99 30.9 23.9 3.30 26.9 22.4 3.62
63†† 36.1 26.3 2.18 33.6 25.2 2.41 31.1 24.1 2.66 28.3 23.0 2.93 26.0 22.0 3.24 23.3 20.9 3.56
62 34.8 32.4 2.17 32.4 31.2 2.39 30.0 29.7 2.65 27.9 27.9 2.93 26.8 26.8 3.25 24.6 24.6 3.58
57 32.7 32.7 2.15 31.0 31.0 2.38 29.9 29.9 2.64 28.7 28.7 2.94 27.3 27.3 3.25 24.8 24.8 3.58
1350
72 41.4 20.9 2.25 40.2 20.6 2.50 38.2 19.9 2.76 36.4 19.4 3.06 34.2 18.8 3.38 31.7 18.2 3.75
67 39.0 27.8 2.24 37.4 27.3 2.48 35.5 26.7 2.74 33.5 26.1 3.03 31.2 25.4 3.35 27.2 23.8 3.68
63†† 36.9 27.8 2.23 34.5 26.8 2.46 31.9 25.7 2.71 29.4 24.6 2.99 26.9 23.6 3.30 24.2 22.4 3.62
62 35.8 34.5 2.22 33.2 32.9 2.45 31.1 31.1 2.70 30.0 30.0 3.00 28.6 28.6 3.32 25.8 25.8 3.65
57 34.8 34.8 2.22 33.3 33.3 2.45 32.0 32.0 2.72 30.7 30.7 3.01 28.3 28.3 3.32 25.9 25.9 3.65
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 036 1.00 1.00 CK5PT 036 1.00 0.94
042 1.00 1.00
COILS + 58CV(A,X)090-16 VARIABLE SPEED FURNACE
CC5A/CD5AW 036 1.00 1.00 CC5A/CD5AA 036 1.00 0.93
CE3AA 036 1.00 1.01 042 1.00 0.92
042 1.00 0.99 CC5A/CD5AW 036 1.00 0.93
CF5AA 036 1.00 1.00 CE3AA 036 1.00 0.94
CK3BA 036 1.00 1.00 042 1.00 0.92
042 1.00 1.00 CK3BA 036 1.00 0.93
CK5A/CK5BA 036 1.00 1.00 042 1.00 0.92
042 1.00 1.00 CK5A/CK5BA 036 1.00 0.93
CK5A/CK5BT 036 1.00 1.00 042 1.00 0.92
042 1.00 1.00 CK5A/CK5BE 042 1.00 0.92
CK5A/CK5BW 036 1.00 1.00 CK5A/CK5BT 036 1.00 0.93
CK5PA 036 1.00 1.00 042 1.00 0.92
042 1.00 1.00 CK5A/CK5BW 036 1.00 0.93
CK5PT 036 1.00 1.00 CK5PA 036 1.00 0.93
042 1.00 1.00 042 1.00 0.92
CK5PW 036 1.00 1.00 CK5PE 042 1.00 0.92
F(A,B)4(A,B)N(F,B,C) 042 1.00 1.00 CK5PT 036 1.00 0.93
F(A,B)4(A,B)N(F,C) 036 1.00 1.00 042 1.00 0.92
FE4ANF 002 1.00 0.95 CK5PW 036 1.00 0.93
003 1.00 0.93
COILS + 58CV(A,X)110-20 VARIABLE SPEED FURNACE
005 1.03 0.94
CC5A/CD5AA 036 1.00 0.93
FG3AAA 036 1.00 1.02
042 1.00 0.93
FK4(C,D)NF 002 1.00 0.95
CC5A/CD5AW 036 1.00 0.93
003 1.00 0.93
042 1.00 0.94
005 1.03 0.94
CE3AA 036 1.00 0.94
FV4(A,B)NF 002 1.00 0.95
042 1.00 0.92
003 1.00 0.93
CK3BA 036 1.00 0.93
005 1.03 0.94
042 1.00 0.93
FX4(A,B)NF 036 0.97 0.99
CK5A/CK5BA 036 1.00 0.93
042 1.00 1.00
042 1.00 0.93
COILS + 58CV(A,X)070-12 VARIABLE SPEED FURNACE CK5A/CK5BE 042 1.00 0.92
CC5A/CD5AA 036 1.00 0.95
CK5A/CK5BT 036 1.00 0.93
CE3AA 036 1.00 0.96
042 1.00 0.93
042 1.00 0.94
CK5A/CK5BW 036 1.00 0.93
CK3BA 036 1.00 0.94
CK5PA 036 1.00 0.93
CK5A/CK5BA 036 1.00 0.94
042 1.00 0.93
CK5A/CK5BE 042 1.00 0.93
CK5PT 036 1.00 0.93
CK5A/CK5BT 036 1.00 0.94
042 1.00 0.93
CK5PA 036 1.00 0.94
CK5PW 036 1.00 0.93
CK5PE 042 1.00 0.93
CK5PE 042 1.00 0.92
