Carrier Performance 13 38TXA User Manual

30
Detailed cooling capacities* continued
See notes on pg. 38.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38TXA036-34 Outdoor Section With CC5A/CD5AA042 Indoor Section
1050
72 40.4 19.6 2.15 39.0 19.2 2.40 37.4 18.6 2.66 35.6 18.0 2.96 33.4 17.3 3.28 30.9 16.4 3.64
67 38.0 25.3 2.14 36.4 24.8 2.38 34.6 24.1 2.65 32.5 23.3 2.94 30.4 22.4 3.24 26.5 20.9 3.57
63†† 34.9 24.6 2.12 32.5 23.6 2.35 30.1 22.5 2.60 27.5 21.4 2.87 24.9 20.3 3.17 22.3 19.2 3.50
62 33.9 30.2 2.12 31.6 29.1 2.34 29.2 27.9 2.59 26.7 26.5 2.86 24.5 24.5 3.17 23.2 23.2 3.51
57 31.3 31.3 2.09 29.5 29.5 2.32 27.5 27.5 2.57 26.4 26.4 2.86 25.1 25.1 3.17 23.6 23.6 3.51
1200
72 41.0 20.3 2.20 39.7 19.9 2.45 38.1 19.4 2.72 36.2 18.9 3.02 33.9 18.1 3.34 31.4 17.3 3.70
67 38.5 26.5 2.19 37.0 26.1 2.43 35.0 25.3 2.69 33.1 24.7 2.99 30.9 23.9 3.30 26.9 22.4 3.62
63†† 36.1 26.3 2.18 33.6 25.2 2.41 31.1 24.1 2.66 28.3 23.0 2.93 26.0 22.0 3.24 23.3 20.9 3.56
62 34.8 32.4 2.17 32.4 31.2 2.39 30.0 29.7 2.65 27.9 27.9 2.93 26.8 26.8 3.25 24.6 24.6 3.58
57 32.7 32.7 2.15 31.0 31.0 2.38 29.9 29.9 2.64 28.7 28.7 2.94 27.3 27.3 3.25 24.8 24.8 3.58
1350
72 41.4 20.9 2.25 40.2 20.6 2.50 38.2 19.9 2.76 36.4 19.4 3.06 34.2 18.8 3.38 31.7 18.2 3.75
67 39.0 27.8 2.24 37.4 27.3 2.48 35.5 26.7 2.74 33.5 26.1 3.03 31.2 25.4 3.35 27.2 23.8 3.68
63†† 36.9 27.8 2.23 34.5 26.8 2.46 31.9 25.7 2.71 29.4 24.6 2.99 26.9 23.6 3.30 24.2 22.4 3.62
62 35.8 34.5 2.22 33.2 32.9 2.45 31.1 31.1 2.70 30.0 30.0 3.00 28.6 28.6 3.32 25.8 25.8 3.65
57 34.8 34.8 2.22 33.3 33.3 2.45 32.0 32.0 2.72 30.7 30.7 3.01 28.3 28.3 3.32 25.9 25.9 3.65
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 036* 1.00 1.00
COILS + 58CV(A,X)070-12 VARIABLE SPEED FURNACE
042 1.00 1.00 CC5A/CD5AA 036 0.98 0.93
CC5A/CD5AW 036 1.00 1.00 CE3AA 036 0.97 0.93
042 0.99 1.00 042 0.99 0.93
CE3AA 036 0.99 1.00 CK3BA 036 0.99 0.93
042 1.00 0.99 CK5A/CK5BA 036 0.99 0.93
CF5AA 036 1.00 1.00 CK5A/CK5BE 042 0.99 0.93
CK3BA 036 1.00 1.00 CK5A/CK5BT 036 0.99 0.93
042 1.00 1.00 CK5PA 036 0.99 0.94
CK5A/CK5BA 036 1.00 1.00 CK5PE 042 0.99 0.93
042 1.00 1.00 CK5PT 036 0.99 0.94
CK5A/CK5BE 042 1.00 0.99
COILS + 58CV(A,X)090-16 VARIABLE SPEED FURNACE
CK5A/CK5BT 036 1.00 1.00 CC5A/CD5AA 036 0.98 0.92
042 1.00 1.00 042 0.98 0.91
CK5A/CK5BW 036 1.00 1.00 CC5A/CD5AW 036 0.98 0.91
CK5PA 036 1.00 1.00 CE3AA 036 0.97 0.92
042 1.00 1.00 042 0.99 0.91
CK5PE 042 1.00 0.99 CK3BA 036 0.99 0.92
CK5PT 036 1.00 1.00 042 0.99 0.92
042 1.00 1.00 CK5A/CK5BA 036 0.99 0.92
CK5PW 036 1.00 1.00 042 0.99 0.92
F(A,B)4BN(F,B,C) 042 1.00 1.01 CK5A/CK5BE 042 0.99 0.91
F(A,B)4BN(F,C) 036 0.99 1.02 CK5A/CK5BT 036 0.99 0.92
FC4CN(F,B) 042 1.00 1.00 042 0.99 0.92
FC4CNF 036 0.99 1.02 CK5A/CK5BW 036 0.99 0.92
FE4ANB 006 1.03 0.89 CK5PA 036 0.99 0.92
FE4ANF 002 1.00 0.94 042 0.99 0.92
003 1.00 0.91 CK5PE 042 0.99 0.91
005 1.03 0.90 CK5PT 036 0.99 0.92
FG3AAA 036 0.97 1.00 042 0.99 0.92
048 1.00 1.01 CK5PW 036 0.99 0.92
FK4DNB 006 1.03 0.89
COILS + 58CV(A,X)110-20 VARIABLE SPEED FURNACE
FK4DNF 001 0.99 0.95 CC5A/CD5AA 036 0.98 0.92
002 1.00 0.94 042 0.98 0.91
003 1.00 0.91 CC5A/CD5AW 036 0.98 0.91
005 1.03 0.90 042 0.98 0.91
FV4BNB 006 1.03 0.89 CE3AA 036 0.97 0.92
FV4BNF 002 1.00 0.94 042 0.99 0.91
003 1.00 0.91 CK3BA 036 0.99 0.92
005 1.03 0.90 042 0.99 0.92
FX4BNF 036 1.00 1.01 CK5A/CK5BA 036 0.99 0.92
042 1.02 1.01 042 0.99 0.92
