Detailed cooling capacities* continued
See notes on pg. 38.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38TXA042-33 Outdoor Section With CD5AA048 Indoor Section continued
1225
72 46.7 22.7 2.49 45.2 22.3 2.77 43.3 21.6 3.09 41.2 20.9 3.44 38.8 20.1 3.83 36.0 19.2 4.26
67 44.0 29.5 2.47 42.3 28.9 2.75 39.8 27.8 3.05 37.7 27.1 3.40 35.4 26.3 3.79 31.4 24.7 4.18
63†† 40.5 28.7 2.44 37.8 27.5 2.70 35.0 26.3 3.00 32.0 25.0 3.32 30.2 24.3 3.70 27.8 23.3 4.11
62 39.3 35.4 2.43 36.7 34.1 2.69 33.9 32.7 2.98 31.1 30.9 3.31 29.5 29.5 3.69 27.9 27.9 4.11
57 36.4 36.4 2.40 34.3 34.3 2.67 32.1 32.1 2.96 30.8 30.8 3.30 29.4 29.4 3.69 27.7 27.7 4.11
1400
72 47.1 23.3 2.55 45.8 23.0 2.83 43.9 22.5 3.15 41.8 21.8 3.51 39.3 21.1 3.90 36.5 20.2 4.33
67 44.3 30.5 2.52 42.7 30.2 2.81 40.5 29.4 3.12 38.4 28.8 3.47 35.9 27.9 3.85 31.7 26.4 4.25
63†† 42.1 30.7 2.51 39.3 29.5 2.78 36.4 28.3 3.07 33.6 27.1 3.40 31.8 26.3 3.79 27.9 24.7 4.18
62 40.5 37.9 2.50 37.8 36.5 2.76 35.0 34.8 3.06 32.7 32.7 3.39 31.2 31.2 3.78 29.5 29.5 4.21
57 38.1 38.1 2.48 36.2 36.2 2.74 35.0 35.0 3.05 33.6 33.6 3.40 32.2 32.2 3.79 29.3 29.3 4.20
1575
72 47.5 23.9 2.61 46.2 23.7 2.90 44.4 23.2 3.22 41.8 22.4 3.56 39.5 21.8 3.95 36.8 21.1 4.40
67 44.9 31.9 2.58 43.0 31.5 2.86 41.1 31.1 3.18 38.8 30.3 3.53 36.3 29.6 3.92 32.0 28.0 4.32
63†† 42.5 32.0 2.57 40.5 31.4 2.85 37.6 30.1 3.15 35.0 29.1 3.48 33.1 28.3 3.87 27.9 26.0 4.24
62 41.6 40.2 2.57 38.9 38.5 2.83 36.5 36.5 3.13 35.4 35.4 3.49 32.7 32.7 3.86 30.7 30.7 4.29
57 40.7 40.7 2.56 39.0 39.0 2.83 37.6 37.6 3.15 35.8 35.8 3.49 33.5 33.5 3.87 30.7 30.7 4.29
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CE3AA 042 1.01 0.98 CK5PT 042 1.00 0.97
048 1.01 0.98 048 1.00 0.95
COILS + 58MVP100-20 VARIABLE SPEED FURNACE COILS + 58MVP120-20 VARIABLE SPEED FURNACE
CC5A/CD5AA 042 1.00 0.98 CC5A/CD5AA 042 1.00 0.98
CC5A/CD5AC 048 0.99 0.96 CC5A/CD5AW 048 1.00 0.96
CD5AA 048 1.00 0.96 CE3AA 042 1.01 0.98
CE3AA 042 1.01 0.98 048 1.01 0.98
048 1.01 0.98 CK3BA 042 1.00 0.97
CK3BA 042 1.00 0.97 048 1.00 0.95
048 1.00 0.95 CK5A/CK5BA 042 1.00 0.97
CK5A/CK5BA 042 1.00 0.97 CK5A/CK5BT 042 1.00 0.97
048 1.00 0.95 CK5A/CK5BW 048 1.00 0.95
CK5A/CK5BT 042 1.00 0.97 CK5PA 042 1.00 0.97
048 1.00 0.95 CK5PT 042 1.00 0.97
CK5PA 042 1.00 0.97 CK5PW 048 1.00 0.95
048 1.00 0.95 — — —
