Table 14 -- Dry Coil Air Delivery* -- Horizontal and Downflow Discharge -- 208/230 VAC 3--Phase Models (Cont)
UNIT
HEATING RISE
RANGE
MOTOR
SPEED
WIRE
COLOR
EXTERNAL STATIC PRESSURE (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0. 6 0.7 0.8 0.9 1
60115
30 - 60
o
FLowStage,
30 - 60
o
FHighStage
Low
1
Blue
CFM 1271 1229 1177 1121 1066 1027 974 942 887 839 BHP 0.19 0.20 0.21 0.23 0.24 0.25 0.26 0.27 0.28 0.29 Low Stage Heat Rise
o
F
(
o
C)
44
(24)
45
(25)
47
(26)
50
(28)
52
(29)
54
(30)
57
(32)
59
(33)
NA NA
High Stage Heat Rise
o
F
(
o
C)
NA NA NA NA NA NA NA NA NA NA
Med-Low
3
Pink
CFM 1340 1299 1240 1191 1139 1091 1050 1001 952 895 BHP 0.22 0.23 0.24 0.25 0.26 0.28 0.29 0.30 0.31 0.32 Low Stage Heat Rise
o
F
(
o
C)
42
(23)
43
(24)
45
(25)
47
(26)
49
(27)
51
(28)
53
(30)
56
(31)
59
(33)
NA
High Stage Heat Rise
o
F
(
o
C)
NA NA NA NA NA NA NA NA NA NA
Medium Red
CFM 1686 1650 1617 1576 1544 1503 1468 1433 1393 1356 BHP 0.42 0.44 0.45 0.46 0.48 0.49 0.51 0.52 0.53 0.55 Low Stage Heat Rise
o
F
(
o
C)
33
(18)
34
(19)
35
(19)
35
(20)
36
(20)
37
(21)
38
(21)
39
(22)
40
(22)
41
(23)
High Stage Heat Rise
o
F
(
o
C)
52
(29)
53
(29)
54
(30)
55
(31)
56
(31)
58
(32)
59
(33)
NA NA NA
Med-High
2
Orange
CFM 1878 1844 1805 1762 1731 1693 1655 1616 1570 1532 BHP 0.50 0.52 0.53 0.54 0.56 0.57 0.59 0.60 0.64 0.63 Low Stage Heat Rise
o
F
(
o
C)
30
(17)
30
(17)
31
(17)
32
(18)
32
(18)
33
(18)
34
(19)
35
(19)
36
(20)
36
(20)
High Stage Heat Rise
o
F
(
o
C)
46
(26)
47
(26)
48
(27)
49
(27)
50
(28)
51
(29)
53
(29)
54
(30)
55
(31)
57
(32)
High
4
Black
CFM 1934 1900 1855 1815 1778 1737 1695 1656 1606 1528 BHP 0.59 0.61 0.62 0.64 0.65 0.67 0.68 0.70 0.70 0.68 Low Stage Heat Rise
o
F
(
o
C)
NA NA
30
(17)
31
(17)
31
(17)
32
(18)
33
(18)
34
(19)
35
(19)
37
(20)
High Stage Heat Rise
o
F
(
o
C)
45
(25)
46
(25)
47
(26)
48
(27)
49
(27)
50
(28)
51
(28)
52
(29)
54
(30)
57
(32)
