Carrier Touch Pilot 33CNTPILOT - Page 5

3
Figure 1 — Carrier Communicating Network (CCN) Bus Wiring
Figure 2 — Touch Pilot Wiring
1
2
3
6
5
4
1
2
3
COMM
GN
D
1000 FT MAXIMUM
DRAIN WIRE (TYP)
BLK (TYP)
WHT (TYP)
RED (TYP)
BYPASS
CONTROLLER
ZONE
CONTROLLER
SYSTEM
PILOT
ZONE
CONTROLLER
BRIDGE
(RECOMMENDED)
1
2
3
1
2
3
CCNCCNCCN CCN
CHILLER
DISPLAY
Figure 3 — Touch Pilot Bezel
Figure 4 — Touch Pilot Surface Mounting
