The power generated by the APS internal power amps has the capacity to damage the drivers, in which case they would not be covered under warranty.
2-Way systeMs specs:
LS1002 LS1202 LS1502 / 1502A
Frequency Response +/- 3dB
85Hz - 20kHz (72Hz - 10dB)
Frequency Response +/- 3dB
76Hz - 18kHz (70Hz - 10dB) 53Hz - 18kHz 47Hz - 10dB) / 350w
RMS (Hi Freq: 50w @ 16 ohms, Lo
Freq. 300w @ 8 ohms)
Power Capacity
200 W continuous, 400 W peak
Power Capacity
300 W continuous, 600 W peak 400 W continuous, 800 W peak
Sensitivity
98 dB SPL, 1W / 1M
Sensitivity
97 dB SPL, 1W / 1M 100 dB SPL, 1W / 1M
Calculated Max SPL
124 dB
Calculated Max SPL
125 dB 129 dB
Nominal Directivity
60 degrees HxV
Nominal Directivity
90 degrees HxV 90 degrees HxV
Nominal Impedance
8 Ohms
Nominal Impedance
8 Ohms 8 Ohms
Enclosure Type
Vented Bass Reflex
BiAmp Impedance
LF 8 Ohms, HF 16 Ohms LF 8 Ohms, HF 16 Ohms
Enclosure Construction
12mm Baltic birch cross grain
laminated plywood
Enclosure Type
Vented Bass Reflex Vented Bass Reflex
Recommended Power Amp
200 W - 400W
Enclosure Construction
12mm Baltic birch cross grain
laminated plywood
12mm Baltic birch cross grain
laminated plywood
Dimensions
12.4”W x 11”D x 18”H
Recommended Power Amp
300 W - 600W 400 W - 800W
Weight
23 lbs.
Dimensions
15”W x 13.2”D x 24.5”H 18”W x 14”D x 27.5”H
Weight
33 lbs. 43 lbs.
3-Way systeMs specs:
LS1503/1503A LS1523 / 1523A LS2153
Frequency Response +/- 3dB
52Hz - 20kHz (46Hz - 10dB) / 425w
RMS (Hi Freq: 50w @ 16ohms, Mid
Freq: 75w @ 16 ohms, Lo Freq. 300w
@ 8 ohms)
51Hz - 20kHz (45Hz - 10dB) /
900w RMS (Hi Freq: 80w @ 16
ohms, Mid Freq: 120w @ 8 ohms,
Lo Freq. 700w @ 4 ohms)
51Hz - 20kHz (45Hz - 10dB)
Power Capacity
400 W continuous, 800 W peak 800 W continuous, 1600 W peak 800 W continuous, 1600 W peak
Sensitivity
101 dB SPL, 1W / 1M 101 dB SPL, 1W / 1M 101 dB SPL, 1W / 1M
Calculated Max SPL
130 dB 133 dB 133 dB
Nominal Directivity
90 degrees H x 60 degrees V 90 degrees H x 60 degrees V 90 degrees H x 60 degrees V
Nominal Impedance
8 Ohms 4 Ohms 4 Ohms
BiAmp Impedance
LF 8 Ohms, MF/HF 8 Ohms LF 8 Ohms, MF/HF 8 Ohms LF 8 Ohms, MF/HF 8 Ohms
Enclosure Type
Vented Bass Reflex Vented Bass Reflex Vented Bass Reflex
Enclosure Construction
12mm Baltic birch cross grain
laminated plywood
12mm Baltic birch cross grain
laminated plywood
12mm Baltic birch cross grain
laminated plywood
Recommended Power Amp
400 W - 800W 800 W - 1600W 800 W - 1600W
Dimensions
18.75”W x 15.5”D x 24”H 22..5”W x 19.75”D x 46.75”H 16.5”W x 14.75”D x 43.75”H
Weight
58 lbs. 105 lbs. 71 lbs.
sUBWooFeR systeMs:
LS1801 / 1801A LS1802 LS1802
Frequency Response +/- 3dB
35Hz - 150Hz (29Hz - 10dB) / 700w
RMS @ 4 ohms
30Hz - 150Hz (24Hz - 10dB) 30Hz - 150Hz (24Hz - 10dB)
Power Capacity
800 W continuous, 1600 W peak 1600 W continuous, 3200 W
peak
1600 W continuous, 3200 W peak
Sensitivity
98 dB SPL, 1W / 1M 102 dB SPL, 1W / 1M 102 dB SPL, 1W / 1M
Calculated Max SPL
130 dB 137 dB 137 dB
Nominal Directivity
N/A N/A N/A
Nominal Impedance
4 Ohms 4 Ohms 4 Ohms
Enclosure Type
Vented Bass Reflex Vented Bass Reflex Vented Bass Reflex
Enclosure Construction
12mm Baltic birch cross grain
laminated plywood
12mm Baltic birch cross grain
laminated plywood
12mm Baltic birch cross grain
laminated plywood
Recommended Power Amp
800 W - 1600W 1600 W - 3200W 1600 W - 3200W
Dimensions
19.5”W x 22”D x 23.5”H 39.5”W x 22”D x 23.5”H 39.5”W x 22”D x 23.5”H
Weight
71 lbs. 119 lbs. 119 lbs.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
IMPORTANT! FOR YOUR PROTECTION, PLEASE READ THE FOLLOWING:
WATER AND MOISTURE: Do not expose this appliance to rain or moisture. Do not use this apparatus near water (in a wet basement,
near a swimming pool, bathtub etc). Care should be taken so that liquids are not spilled or splashed onto the unit. Do not place
objects filled with liquids such as beverage containers on this apparatus.
POWER SOURCES: The appliance should be connected to a power supply only of the type described in the operating instruc-
tions or as marked on the unit. Unplug during lightning storms.
GROUNDING OR POLARIZATION: Precautions should be taken so that the grounding or polarization means of an appliance
is not defeated.
POWER CORD: Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs and the point where they exit from the appliance. The plug
or power inlet is the disconnect device and shall remain readily operable.
PLACEMENT: Do not block ventilation openings. Do not install near heat sources such as radiators, stoves or other products
that produce heat. Do not install in a confined area. Use only mounting hardware such as brackets and tripods recommended
by the manufacturer.
SERVICING: The user should not attempt to service the unit. All servicing should be referred to qualified service personnel.
FUSING: If your unit is equipped with a fuse receptacle, replace only with the same type fuse. Refer to replacement text on
the unit for correct fuse type.
This symbol is intended to alert
the user to the presence of
uninsulated “dangerous voltage”
within the product’s enclosure
that may be of sufficient mag-
nitude to constitute a risk of
electric shock to persons.
This symbol is intended to alert the
user to the presence of important
operating and maintenance (servic-
ing) instructions in the literature
accompanying the appliance.
LIMITED WARRANTY
Your Carvin product is guaranteed against failure for 3 YEARS unless otherwise stated. Carvin will service
and supply all parts at no charge to the customer providing the unit is under warranty. Shipping costs are
the responsibility of the customer. CARVIN DOES NOT PAY FOR PARTS OR SERVICING OTHER THAN OUR
OWN. A COPY OF THE ORIGINAL INVOICE IS REQUIRED TO VERIFY YOUR WARRANTY. This warranty
does not cover, and no liability is assumed, for damage due to: natural disasters, accidents, abuse, loss of
parts, lack of reasonable care, incorrect use, or failure to follow instructions. This warranty is in lieu of all
other warranties, expressed or implied. No representative or person is authorized to represent or assume
for Carvin any liability in connection with the sale or servicing of Carvin products. CARVIN SHALL NOT BE
LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.
When RETURNING merchandise to the factory, you must call for a return authorization number. If your
unit is out of warranty, you will be charged the current FLAT RATE for parts and labor to bring your unit
up to factory specifications.
HELP SECTION
1) UNIT WILL NOT TURN ON: Check the power to the AC cord. Check for tripped circuit breakers,
unplugged extension cords or power-strip switches that may be turned off. Check the fuse or circuit breaker
on the unit if available. If the fuse has been replaced with the proper value and the fuse fails again, or the
internal circuit breaker activates after reset, the unit will require servicing.
2) NO OUTPUT with POWER light ON: Shipping damage will be the primary reason for your product to not
function properly. Please give us a call to help you determine the problem.
3) KEEP YOUR UNIT LOOKING NEW: Use only a dry cloth to wipe the control and venting areas. Surfaces
without openings may be cleaned with a damp cloth.
THIS UNIT CONTAINS HIGH VOLTAGE INSIDE!
REFER SERVICING TO A QUALIFIED TECHNICIAN
CAUTION
