the control room during a mix, (requiring the faders to be up). All the 2-Track

interconnects as well as all the channels are assignable to the 2-Track Master

Outputs, and the 2-Track Master outputs are usually normalized to your 2-track

tape deck for mixdown. In a live situation the 2-Track outputs may be used to drive

the main system. So, it is a good idea to experiment with the 2-Track Master Faders

to determine their best operating parameters for your application, getting a feel

for levels to your 2-track tape deck and control room.

))

* The Phantom Power switch (when depressed) will provide +48V D.C.

voltage to pins #2 and #3 on the mic inputs of your console. This voltage is

required to operate condenser type microphones. Without Phantom Power you

simply would not be able to use these types of microphones with your console,

unless you purchased a special outside "Phantom" power supply.

If most of your microphones are dynamic (not requiring

phantom power) and you are operating several condenser

type mics, you will need to depress the phantom power

switch. This will not affect the dynamic microphones

operation or reliability.

Before using the Phantom Power switch with wireless

microphones, check to be sure your (reciever unit)

is tolerant of phantom power. It is best to consult

with the microphone's manufacturer to be absolutely

certain.

* Directly next the Phantom Power switch is a small BNC connector

labled (6 volt). This is a recepticle for a BNC style "Little Lite". This small 6 volt

light is used to provide some illumination to your console when it may be used in

the dark or dimly lit areas. It operated on 6 volts and provides an excellent source

of light. It may be positioned to see back panel connections or front panel

controls in dimly lit areas. The mini-light is offered by Carvin & may be

purchased for $25.00 dollars. (Model #G-12)

))

* The eight VU meters on the MX2488 normally monitor the output

levels from the eight output channels of the console. By depressing the "Cue"

meter function switch, the VU meters (Assigned to output channels #5 & #6) will

meter the Cue #1 and #2 output signals. This will give you an instant ready

reference to the output lovels of your Cue sends. If you depress the (L-R) switch,
