1-19

))

* The output channel fader is always fed from the channels regardless

of the position of the "Tape" switch. This fader is dedicated to adjusting the print

(record) levels to the multi-track recorder. The output of this fader also feeds the

2-Track monitor section of the console for rough control room 2-Track mixing.

This fader is usually operatedlower than the channel faders. The normal settings

are around -20 to -3 on the calibrated fader markings. Adjustments of this fader

are metered by the (8) main VU meters. It is also advisable to check the VU levels

on your tape deck to be sure they are properly calibrated, assuring that you are

not overdriving your multi-track tape deck.

))

* This jack is a "Line Input" or pre-amp input connection. It is

designed to accept signals normally too strong for the mic input. (See Section #3-

Mic/Line Switch). Line lwvel (pre-amp) siganls are tupically from 200 millivolts

to 2 volts. These inputs will accept signals form any line level source including

tape deck outputs, signal processing devices, keyboard or instrument amplifier

outputs. The input utilizes a single ended 1/4" phone plug connection. Most

cassette tape decks and other line sources may use a DIN type RCA phono plug

connector. This may require the use of an adaptor or special wired cord to plug

the outputs of your tape deck into this input. However, this is perfectly

acceptable.

"Line Inputs" of channnels #1 through #8 are internally

connected to the 2-Track Interconnect section at the output

channels of the console. These "Line Inputs" are normally

connected to the outputs of the multi-track tape deck for

quick playback, rough 2-Track mixing and overdubbing.

These inputs may be accessed for playback by depressing the

"Tape" seitches at the output section of the console. The

playback signals may be manipulated and rough mixed using

the 2-Track Level faders directly above the Output Channel

Faders. Depressing the Mic/Line switches on the channels will

direct the multi-track outputs through channel #1 through #8

input channels for final mixdowns.

))
