CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
SAFETY INSTRUCTIONS (EUROPEAN)
The conductors in the AC power cord are colored in accordance with the following code.
GREEN & YELLOW—Earth BLUE—Neutral BROWN—Live
U.K. MAIN PLUG WARNING: A molded main plug that has been cut off from the cord is
unsafe. NEVER UNDER ANY CIRCUMSTANCES SHOULD YOU INSERTADAMAGED
OR CUT MAIN PLUG INTO A POWER SOCKET.
IMPORTANT! FOR YOUR PROTECTION, PLEASE READ THE FOLLOWING:
WATER AND MOISTURE: Appliance should not be used near water (near a bathtub, washbowl,
kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc). Care should be taken
so that objects do not fall and liquids are not spilled into the enclosure through openings.
POWER SOURCES: The product should be connected to a power supply only of the type described
in the operating instructions or as marked on the appliance.
GROUNDING OR POLARIZATION: Precautions should be taken so that the grounding or polar-
ization is not defeated.
POWER CORD PROTECTION: Power supply cords should be routed so that they are not likely
to be walked on or pinched by items placed upon or against them, paying particular attention
to cords at plugs, convenience receptacles, and the point where they exit from the appliance.
SERVICING: The user should not attempt to service the appliance beyond that described in the
operating instructions. All other servicing should be referred to qualified service personnel.
FUSING: If your unit is equipped with a fuse receptacle, replace only with the same type fuse.
Refer to replacement text on the unit for correct fuse type.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL! THIS UNIT CONTAINS HIGH
VOLTAGE INSIDE!
CAUTION
RISK OF ELECTRIC SHOCK
REPLACEMENT PARTS LIST FOR R600/R1000
This symbol is intended to
alert the user to the pres-
ence of uninsulated “dan-
gerous voltage” within the
product’s enclosure that may be of suf-
ficient magnitude to constitute a risk of
electric shock to persons.
This symbol is
intended to alert the
user to the presence of
important operating
and maintenance (servicing) instruc-
tions in the literature accompanying
the appliance.
LIMITED WARRANTY
Your Carvin product is guaranteed against failure for 1 YEAR unless otherwise stated.
Carvin will service and supply all parts at no charge to the customer providing the unit
is under warranty. Shipping costs are the responsibility of the customer. CARVIN DOES
NOT PAY FOR PARTS OR SERVICING OTHER THAN OUR OWN. A COPY OF THE ORIG-
INAL INVOICE IS REQUIRED TO VERIFY YOUR WARRANTY. Carvin assumes no respon-
sibility for horn drivers or speakers damaged by this unit. This warranty does not cover,
and no liability is assumed, for damage due to: natural disasters, accidents, abuse, loss
of parts, lack of reasonable care, incorrect use, or failure to follow instructions. This war-
ranty is in lieu of all other warranties, expressed or implied. No representative or person
is authorized to represent or assume for Carvin any liability in connection with the sale
or servicing of Carvin products.
CARVIN SHALL NOT BE LIABLE FOR INCIDENTAL OR CON-
SEQUENTIAL DAMAGES.
When RETURNING merchandise to the factory, you may call for a return authoriza-
tion number. Describe in writing each problem. If your unit is out of warranty, you
will be charged the current FLAT RATE for parts and labor to bring your unit up to fac-
tory specifications.
MAINTAINING YOUR EQUIPMENT
Avoid spilling liquids or allowing any other foreign matter inside the unit. The panel of
your unit can be wiped from time to time with a dry or slightly damp cloth in order to
remove dust and bring back the new look.
As with all pro gear, avoid prolonged use in
caustic environments (salt air). When used in such an environment, be sure the ampli-
fier is adequately protected by rack, covers, etc..
R600 / R1000
03-00560 2 EACH STANDOFF W/ANTI SPIN .56X.25"
insert into PCB at B1, B2
03-15010 1 EACH TOROID PAD 4.75" OD X 2" ID X0
03-18200 2 EACH CABLE TIE 8"LX .10"W 2" BNDLE
03-63343 1 EACH STDOFF ALUM ROU #6 L=.437"
03-80602 4 EACH GROMMET NAT PLASTI SCRW #8/10
03-82061 3 EACH CABLE TIE 14.5Lx .19Wx 2" BNDL
03-90080 1 EACH GUARD FAN PLASTIC 80x80mm
05-01603 1 EACH PWR AC 3/16AWG 8' 2" W/PLUGS
05-60420 1 EACH CABLE RIBBON 24A 10P/ 8" W/HDR
05-60435 1 EACH CABLE RIBBON 24A 10P/14" W/HDR
05-62430 1 EACH CABLE RIBBON 24A 2P/12" W/HDR
H13A to H13B
05-64410 2 EACH CABLE RIBBON 24A 4P/ 4" W/HDR
H2A to H2B, H5A, to H5B
05-64420 1 EACH CABLE RIBBON 24A 4P/ 8" W/HDR
H4A to H4B
05-84628 1 EACH CABLE ASSY, 4C 280MM
05-84616 1 EACH CABLE ASSY, 4C 160MM
06-10120 2 EACH MS PPH 8-32X .500 TYPE F BLACK
06-10133 2 EACH SMS PPH (#8x.375) TYPE A BLK.
06-03125 13 EACH WSH INTERNAL LOCK 5/16 ID
06-10034 2 EACH SMS PPH #4X 1.00 TYPE AB BLK
06-10045 7 EACH SMS PFH #6X .375 TYPE AB BLACK
06-10061 2 EACH SMS PPH #6 X .375 TYPE A BLACK
06-10080 2 EACH MS PPH 6-32X .750 BLACK
06-10150 4 EACH MS PPH 10-32X .375 BLACK
06-10151 4 EACH MS PTH 10-32X .500 BLACK
06-10159 2 EACH MS PPH 10-32X .500 TYPE F BLK
06-10174 4 EACH SMS POH #10X 1.25 TYPE A BLACK
06-10196 1 EACH MS CTH #1/4-20X 3.00 BOLT BLK
06-11700 13 EACH NUT METRIC 7MM BLACK ALPHA
06-30029 2 EACH WSH FLT #8 STEEL CLEAR ZINC
06-30035 4 EACH WSH FLANGED #10 BLACK ZINC
06-45001 2 EACH NUT CHROME FOR 21-01804 JACK
06-45002 2 EACH BEZEL BLACK FOR 21-01804 JACK
06-45003 2 EACH WASHER BLACK FOR 21-01804 JACK
06-50035 5 EACH NUT KEP #6-32 ZINC CADMIUM
06-50051 8 EACH NUT KEP #10-32 ZINC CADMIUM
06-50061 1 EACH NUT HEX #1/4-20 ZINC W/NYLN IN
06-50545 10 EACH NUT PLSTC FLANGED
03-63294 1 EACH STANDOFF ALUM 6-32x .25x .94
07-10813 1 EACH KNOB "8" ROTARY RED
07-70183 9 EACH CAP EQ GREY .093X .250
07-77708 13 EACH KNOB RED ANODIZE W/SET SCREW
10-10008B 1 EACH CHASSIS 2 SPACE UNIVERSAL
10-15045 1 EACH PLATE TOROID 4.5" DIA 14A GALV
10-40611-1 1 EACH PANEL FRONT 2 SPACE R600
10-40611-2 1 EACH PANEL FRONT 2 SPACE R1000
10-40605 1 EACH PANEL COVER R600/1000 BASS AMP
15-70160-1TOROID 120V R600
15-10172-1TOROID 120V R1000
20-32002 1 EACH CONNECT THRU .100" 22AWG 2 PIN
25-31350 1 EACH SWITCH DPST ROCKER BLACK POWER
76-00001 1 EACH WARRANTY CARD "CARVIN"
76-40000 1 EACH MANUAL R600/1000/RC210T/RL6815
77-00010 1 EACH LABEL CAUTION ELECTRICAL SHOCK
77-02800 1 EACH LABEL AC CORD INSERTION WARNG
77-40608 1 EACH LABEL LEXAN R1000 REAR
77-40609 1 EACH LABEL LEXAN R600 REAR
80-40626 1 EACH PCB ASSY MAIN R600 SMT
80-41000 1 EACH PCB ASSY MAIN R1000 SMT
SV2 1 EACH CABINET 2-SPACE R600 BASS AMP
80-40626 / 80-41000 REV N
03-00450 1 EACH INSLTR 9.125x1.5x.01" SGL ADHV
03-00451 1 EACH INSLTR 9.125x1.5x.02" DBL ADHV
03-00475 1 EACH SPACER PAD .1X .4X .75 W/ADHSV
03-00503 4 EACH INSULATOR .36X .36X .20" 85deg
03-44262 4 EACH WASHER NYLON .115IDx.25ODx.062
03-50135 8 EACH STANDOFF LED .500 X .135 T1
D1, D4, D5, D6, D11, D21, D103, D203
03-82061 1 EACH CABLE TIE 14.5Lx .19Wx 2" BNDL
06-10028 12 EACH MS PPH 4-40X .500 ZINC TYPE F
06-10032 4 EACH MS PPH 4-40X 1.500 TYPE F ZINC
07-01602 5 EACH KNOB "6" 6x6x9.7mm GREY CAP
07-01603 3 EACH KNOB "6L" 6x6x17.4mm GREY CAP
12-00860 2 EACH HEATSINK 9"L 2pc FAN MOUNTED
12-57462 2 EACH HEATSINK VERT W/TABS T0-220
VR1, VR2
15-00105 2 EACH COIL AIR 1.5uH 14AWG
L100, L200
21-01804 2 EACH JACK .250 90d STEREO W/CRM NUT
J15, J16
21-31100 1 EACH RECEPTACLE AC W/FAST-ON CHASS
PL1
21-40001 1 EACH XLR MALE CON NEUTRIK #NC3MAV
J10
21-45000 3 EACH SPEAKON 4-POLE PCMTG #NL4MD-V
J6, J7, J8,
21-50345 6 EACH JACK .250" PHONE MONO PCB MTG
J4, J5, J9, J11, J102, J202
21-50545 4 EACH JACK .250" PHONE STEREO PCB MT
J1, J13, J2, J3
23-03529 2 EACH FUSEHOLDER CLIPS 3AG VERT MTG
F1
23-08604 5 EACH CONNECT HEADER .086" 4 PIN
H1A, H1B, H6A, H6B, H10
23-08609 1 EACH CONNECT HEADER .086" 9 PIN
H7
23-10002 3 EACH CONNECT HEADER .100" 2 PIN
H8, H9, H12
23-11002 2 EACH CONNECT HEADER 2 PIN STRAIGHT
H13A, H13B
23-11004 6 EACH CONNECT HEADER 4 PIN STRAIGHT
H2A, H2B, H4A, H4B, H5A, H5B
23-11010 4 EACH CONNECT HEADER 10 PIN STRAIGHT
H3A, H3B, H11A, H11B
25-02201 8 EACH SWITCH DPDT PUSH PC MTG LOCKNG
S1, S2, S3, S4, S5, S6, S7, S9
30-40600M1 EACH PCB CARD MAIN R600/R1000 REVI
42-10363 2 EACH CAP ELEC 10,000 MFD 63V 20% C501, C502
42-22235-1 EACH CAP ELEC 2,200 MFD 35V 20%
C503, C504
47-10235-1 1 EACH CAP ELEC 1,000 MFD 35V 20%
C507
47-47125-1 EACH CAP ELEC 470 MFD 25VOLT 20%
C71
49-10212 5 EACH 0.001UF SMT 10% FILM 0805 50V
C3, C44, C4, C403, C56
49-10312 13 EACH 0.01UF SMT 10% FILM 080550V
C15, C181, C28, C281, C29, C36, C45
C50, C51, C89, C11, C39, C12
49-10451 22 EACH 0.1 uF SMT 10% FILM 1206 50V
C14, C270, C5, C35, C37, C62, C63, C96, C121
C221, C23, C31, C33, C75, C83, C85, C99
C100, C101, C310, C505, C506
49-12152 5 EACH 120PF SMT 5% CERAMIC 0805
C57, C58, C59, C67, C72
49-18152 1 EACH 180PF SMT 5% CERAMIC 0805,C6
49-22035 24 EACH SMT CAP 22uF 35v ELECTROLITIC
C102, C18, C20, C27, C313, C318, C401
C10, C404, C406, C407, C408, C409, C410, C52
C64, C65, C69, C7, C70, C76, C77, C82, C186
49-22212 3 EACH 0.0022UF SMT 10% FILM 0805 50V
C42, C38, C97
49-22312 6 EACH 0.022UF SMT 10% FILM 0805 50V
C26, C32, C43, C54, C55, C34
49-27052 6 EACH 27 PF SMT 5% CERAMIC 0805
C84, C88, C93, C94
C175, C275
49-33152 9 EACH 330PF SMT 5% CERAMIC 0805
C30, C49, C60, C73, C74, C78, C79, C80, C81
49-33212 5 EACH 0.0033UF SMT 10% FILM 0805 50
C1, C17, C22, C40, C98
49-33312 2 EACH 0.033UF SMT 10% FILM 0805 50V
C16, C25
49-39052 7 EACH 39PF SMT 5% CERAMIC 0805
C176, C19, C24, C276, C405, C53, C8,
49-47212 3 EACH 0.0047uF SMT FILM 0805 50V
C47, C86, C317
49-47312 11 EACH 0.047UF SMT 10% FILM 0805 50V
C2, C90, C92, C95, C180, C280, C61, C87, C9, C91
C41
49-56152 14 EACH 560PF SMT 5% CERAMIC 0805
C13, C21, C46, C48, C66, C68
C182, C183, C184, C185,
C282, C283, C284, C285
49-82052 2 EACH 82PF SMT 5% CERAMIC 0805
C177, C277
54-47025-1 1 EACH RES 470.00 OHM 2.00W 5% CARBON
R156
55-02205 8 EACH RES .22 OHM 5W 5% SB VERT
R153, R155, R161, R163, (R1000 only R169, R171)
R253, R255, R261, R263 , (R1000 only R269, R271)
55-05025 2 EACH RES 5.00 OHM 5W 5% SB VERT
R186, R286
55-30035 1 EACH RES 3.00KOHM 5W 5% SB WIRE
R103
56-27025 1 EACH RES 270.00 OHM 10W 10% SB SDOF
R105
58-10015 2 EACH 10.5 SMT .25W 1206 1%
R16, R210
58-10025 13 EACH 100.5 SMT .25W 1206 1%
R127, R128, R135, R235, R405, R54, R212
R129, R165, R166, R167, R211, R154
58-10035 19 EACH 1K SMT .25W 1206 1%
R114, R117, R118, R119, R120, R13, R137, R142
R143, R144, R145, R237, R242, R243, R244, R245
R318, R325, R42,
58-10045 45 EACH 10K SMT .25W 1206 1%
R102, R104, R106, R152, R116, R123, R124, R125
R126, R177, R188, R2, R320, R277, R194, R324,
R407, R408, R414, R48, R49, R421, R422, R52,
R58, R78, R82, R196, R98, R424, R425
R168, R170, R172, R173, R174, R180, R181,
R183, R184, R190, R417, R198, R188, R185
58-10055 15 EACH 100K SMT .25W 1206 1%
R14, R1, R178, R179, R25, R278, R279, R331, R35,
R402, R410, R87, R93, R7, R198
58-10065 6 EACH 1M SMT .25W 1206 1%
R157, R158, R159, R160, R202, R191
58-15025 17 EACH 150ohm SMT .50W 1206 1%
R132, R148, R248, R406, R409, R146, R149, R216
R217, R219, R220, R222, R223, R224, R225,
R246, R249
58-15035 1 EACH 1.5K SMT .25W 1206 1% R62
58-15045 4 EACH 15K SMT .25W 1206 1%
R176, R276, R45, R107
58-15055 11 EACH 150K SMT .25W 1206 1%
R17, R3, R30, R37, R71, R77, R22
R189, R289, R204, R111
58-18035 4 EACH 1.8K SMT .25W 1206 1%
R66, R64, R315, R312
58-22035 14 EACH 2.2K SMT .25W 1206 1%
R133, R233, R39, R50, R51, R60
R68, R70, R72, R74, R76, R19, R100, R101
58-22045 20 EACH 22K SMT .25W 1206 1%
R109, R110, R130, R131, R230, R231, R26, R193
R31, R317, R32, R327, R33, R94
R34, R5, R205, R206, R207, R208
58-22055 5 EACH 220K SMT .25W 1206 1%
R6, R175, R95, R69, R23
58-27045 1 EACH 27K SMT .25W 1206 1%
R323
58-33035 3 EACH 3.3K SMT .25W 1206 1%
R192, R209, R329
58-33045 EACH 33K SMT .25W 1206 1%
R108, R113, R138, R199, R238,
R319, R415, R53, R57, R80, R84, R9
58-36055 7 EACH 365K SMT .25W 1206 1%
R36, R65, R67, R73, R75, R61, R63
58-47005 2 EACH 4.7 SMT .25W 1206 1%
R200, R201
58-47025 6 EACH 470.5 SMT .25W 1206 1%
R11, R140, R24, R240, R413, R418
58-47035 14 EACH 4.7K SMT .25W 1206 1%
R18, R134, R139, R141, R234, R239
R241, R326, R41, R43, R44, R47, R88, R89
58-47045 30 EACH 47K SMT .25W 1206 1%
R55, R56, R85, R81, R20
R311, R314, R112, R213, R21
R121, R122, R4, R27, R28, R29, R38, R40,
R46, R86, R90, R91, R92, R97,
R195, R197, R10, R96, R99, R115
58-47055 4 EACH 470K SMT .25W 1206 1%
R214, R322, R15, R203
58-56035 1 EACH 5.6K SMT .25W 1206 1%
R321
58-68025 2 EACH 680 SMT .25W 1206 1%
R147, R247
58-68035 3 EACH 6.8K SMT .25W 1206 1%
R12, R79, R83
58-68045 2 EACH 68K SMT .25W 1206 1%
R8, R330
58-92201 12 EACH 22 SMT 1W 2512 20%
R136, R150, R151, R182, R332, R333
R334, R335, R250, R251,
R419, R420
60-21193-1 4 EACH TRNS BIPOLAR MJL21193-PREPPED
Q112, Q113, Q212, Q213 , (R1000 only Q114, Q214)
60-21194-1 4 EACH TRNS BIPOLAR MJL21194-PREPPED
Q108, Q109, Q208, Q209, (R1000 only Q110, Q210)
60-15032 2 EACH TRANS MJE15032 NPN T0-220
Q107, Q207
60-15033 2 EACH TRANS MJE15033 PNP T0-220
Q111, Q211
60-25458-12 EACH IC J-FET 2N5458 PREP
Q12, Q13
60-35041 1 EACH RECTIFIER BRIDGE 35AMP/400V PC
BR1
60-50253 2 EACH OPTO ISOLATOR VACTROL AXIAL
OP1, OP2
60-55500-2 2 EACH TRANS 2N5550 HV NPN 250V T0-92
Q106, Q206
60-75320 5 EACH LED RED DIFFUSED 3MM T-1.00
D1, D103, D11, D203, D4 (WITH STANDOFF)
60-75330 2 EACH LED GREEN DIFFUSED 3MM T-1.00
D6, D21 (WITH STANDOFF)
60-75340 1 EACH LED YELLOW DIFFUSED 3MM T-1.00
D5 (WITH STANDOFF)
60-78150-11 EACH REG VOLT 15+V 1A (PREPPED)
VR1
60-79120-11 EACH REGULATOR VOLTAGE 12 (PREPPED) Q7
60-79150-1 1 EACH REG VOLT 15-V 1A (PREPPED) VR2
61-60010 2 EACH DIODE ULTRA-FAST SWTCH 600V 1A
D502, D506
62-06001 9 EACH DIODE ULTRA FAST 600V 1A SMA
D18B, D108B, D109B, D208B, D209B, D501B
D503B, D504B, D505B
62-00014 1 EACH MMBTA14 SOT-23 SMT Q1
62-19140 21 EACH 1N914 HI SPD SMT 250mW DIODE
D10, D106, D107, D111, D12, D13, D14, D15
D16, D17, D2, D206, D207, D3, D310, D311, D8, D9
D7, D19, D312
62-29010 2 EACH NJM2901SMT SNGLE SUPPLY
A11, A22
62-03400 5 EACH TRANSISTOR SMT MJD340
Q102, Q105, Q202, Q205, Q301
62-03500 4 EACH TRANSISTOR SMT PNP MJD350
Q103, Q104, Q203, Q204
62-04391 4 EACH TRANSISTOR SMT MMBF4391LT1
Q2, Q3, Q4, Q5
62-20430 2 EACH NJM2043SMT(TESTED) DUAL HFREQ
A17, A18
62-45650 21 EACH NJM4565 SMT DUAL HI FREQ
A1, A2, A3, A4, A5, A6, A7, A8, A9, A10, A23
A12, A13, A14, A15, A16, A19, A20, A21
A24, A25
62-54001 3 EACH MMBT5401LTI PNP SOT-23 SMT
Q117, Q217, Q303
62-55500 4 EACH MMBT5550 NPN SOT-23 Q6, Q10, Q9, Q302
70-02408 1 EACH FAN DC24V 80x80x25mm 42cfm SUN
70-05713 3 EACH RELAY SPDT 12A@120VAC/24V COIL
K1, K100, K200
70-22115 1 EACH FUSE MDQ 15.00A SLOW 6.35X32MM
71-09253 1 EACH POT 9 "D-P" 25F B50K- P11
71-24450 2 EACH POT VERT TRIMMER 500ohm
P101, P201
71-16501 10 EACH POT 16 F15 B50K POI
P1, P2, P3, P4, P5, P6, P7, P8, P10, P12
71-10334 9 EACH FADER 30MM SL30V3-B10K-L15D(G)
P13, P14, P15, P16, P17, P18, P19, P20, P21
72-16503 3 EACH POT 16 F15 15C50Kx2 POI
P9, P23, P22
To Previous Page
Loading...
Need help?
General
