FIG NO. PIÈCE NO. DESCRIPTION
M22904937A
WWW.CARVINPOOL.COM
Replacement Parts (Fig. 9)
5 & 5a
7
8
9
10
11
12
13
14
15
16
1
2
3
4
6
17
18
19
20
21
1
2
3
4
42-1679-70-R
Strainer Quarter-Turn Ringlok
39-0789-03-R
Strainer Cover
47-0352-41-R
Strainer O-ring
16-1052-15-R Strainer Basket
5
6
16-1102-47-R
ORKA inground Strainer Pump Body 2’’
5a
16-1102-12-R
ORKA inground Strainer Pump Body 1’’1/2
31-1609-06-R2
Drain Plug with O-ring ( 2 Per Bag)
7
8
47-0361-08-R
ORKA Strainer Body Main O-ring
06-0153-09-R
Diffuser 5’’ OD9
10
47-0214-06-R
Diffuser O-Ring
10-1462-07-R
Floating Eye Seal
11
12
05-3936-08-R
Impeller for 3/4 hp motors
05-3937-07-R
Impeller for 1 hp motors
05-3939-05-R
Impeller for 1.5 hp motors
05-3940-02-R
Impeller for 2 hp motors
10-0802-08-R
Mechanical Seal Assembly
13
14
02-5436-58-R
ORKA Motor Bracket for inground pool pump
17
18
14-2630-32-R
Robertson/Phillips Pan Head Self Tap Screw 1/4-20 x 1’’1/4
19
20
12-2735-46-R
ORKA pump base
14-4207-19-R
Hex Washer Self-Tap Screw #8-16 x 1’’1/4 StnStl 316
21
14-0722-01-R4
3/8’’ Stainless Steel Washer (4 per bag)
15
16
Flinger
Motor see page A07
22-3403-05-R
14-4361-17-R4
Hex Nut 3/8-16 x 21/64 THK - (4 per bag)
14-1296-37-R4 Hex Cap Machine Screw 3/8-16 x 1’’1/2
(4 per bag)
