CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
SAFETY INSTRUCTIONS (EUROPEAN)
The conductors in the AC power cord are colored in accordance with the following code.
GREEN & YELLOW—Earth BLUE—Neutral BROWN—Live
U.K. MAIN PLUG WARNING: A molded main plug that has been cut off from the cord is
unsafe. NEVER UNDER ANY CIRCUMSTANCES SHOULD YOU INSERT A DAMAGED
OR CUT MAIN PLUG INTO A POWER SOCKET.
IMPORTANT! FOR YOUR PROTECTION, PLEASE READ THE FOLLOWING:
WATER AND MOISTURE: Appliance should not be used near water (near a bathtub, washbowl,
kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc). Care should be taken
so that objects do not fall and liquids are not spilled into the enclosure through openings.
POWER SOURCES: The appliance should be connected to a power supply only of the type described
in the operating instructions or as marked on the appliance.
GROUNDING OR POLARIZATION: Precautions should be taken so that the grounding or polar-
ization means of an appliance is not defeated.
POWER CORD PROTECTION: Power supply cords should be routed so that they are not likely
to be walked on or pinched by items placed upon or against them, paying particular attention
to cords at plugs, convenience receptacles, and the point where they exit from the appliance.
SERVICING: The user should not attempt to service the appliance beyond that described in the
operating instructions. All other servicing should be referred to qualified service personnel.
FUSING: If your unit is equipped with a fuse receptacle, replace only with the same type fuse.
Refer to replacement text on the unit for correct fuse type.
REFER SERVICING TO QUALIFIED SER-
VICE PERSONNEL! THIS UNIT CON-
TAINS HIGH VOLTAGE INSIDE!
CAUTION
RISK OF ELECTRIC SHOCK
Ref. Des.
Carvin P/N Description
A1 60-45580 Op Amp MC4558
A10 60-45580 Op Amp MC4558
A2 60-45580 Op Amp MC4558
A3 60-45580 Op Amp MC4558
A4 60-45580 Op Amp MC4558
A5 60-45580 Op Amp MC4558
A6 60-45580 Op Amp MC4558
A7 60-45580 Op Amp MC4558
A8 60-45580 Op Amp MC4558
A9 60-45580 Op Amp MC4558
C1 45-82052 82PF 500V
C10 47-22051 22µF 50V
C100 46-10412 0.1µF 100V
C101 45-39052 39PF 500V
C102 47-22051 22µF 50V
C103 46-10212 0.001µF 100V
C104 46-10212 0.001µF 100V
C105 46-22312 0.022µF 100V
C106 47-22051 22µF 50V
C107 46-33212 0.0033µF 100V
C108 45-12152 120PF 500V
C109 47-22051 22µF 50V
C11 47-22051 22µF 50V
C110 45-39052 39PF 500V
C12 45-12152 120PF 500V
C13 45-12152 120PF 500V
C14 48-01031 1µF 35V
C15 47-10225 1000µF 25V
C16 47-22151 220µF 50V
C17 46-10312 0.01µF 100V
C18 47-22151 220µF 50V
C19 45-10551 0.1µF 50V
C2 47-22051 22µF 50V
C20 47-10225 1000µF 25V
C200 46-10412 0.1µF 100V
C201 45-82052 82PF 500V
C202 45-82052 82PF 500V
C203 47-22051 22µF 50V
C204 47-22051 22µF 50V
C205 45-27052 27PF 500V
C206 45-27052 27PF 500V
C207 47-22051 22µF 50V
C208 46-10412 0.1µF 100V
C209 46-10312 0.01µF 100V
C21 47-10225 1000µF 25V
C210 47-22051 22µF 50V
C211 45-39052 39PF 500V
C212 47-22051 22µF 50V
C213 45-12152 120PF 500V
C214 45-39052 39PF 500V
C23 42-47251 4700µF 50V
C24 42-47251 4700µF 50V
C25 46-10312 0.01µF 100V
C26 47-10061 10µF 63V
C27 47-10061 10µF 63V
C28 47-10061 10µF 63V
C29 45-10551 0.1µF 50V
C3 45-56152 560PF 500V
C30 45-10551 0.1µF 50V
C300 46-10412 0.1µF 100V
C301 45-82052 82PF 500V
C302 45-82052 82PF 500V
C303 47-22051 22µF 50V
C304 47-22051 22µF 50V
C305 45-27052 27PF 500V
C306 45-27052 27PF 500V
C307 47-22051 22µF 50V
C308 46-10412 0.1µF 100V
C309 46-10312 0.01µF 100V
C31 45-10551 0.1µF 50V
C310 47-22051 22µF 50V
C311 45-39052 39PF 500V
C312 47-22051 22µF 50V
C313 45-12152 120PF 500V
C314 45-39052 39PF 500V
C32 45-10551 0.1µF 50V
C33 45-10551 0.1µF 50V
C34 45-10551 0.1µF 50V
C35 45-10551 0.1µF 50V
C36 45-10551 0.1µF 50V
C37 47-10061 10µF 63V
C38 45-12152 120PF 500V
C39 41-47321 0.047µF 250 VAC
C4 45-56152 560PF 500V
C400 46-10412 0.1µF 100V
C401 45-82052 82PF 500V
C402 45-82052 82PF 500V
C403 47-22051 22µF 50V
C404 47-22051 22µF 50V
C405 45-27052 27PF 500V
C406 45-27052 27PF 500V
C407 47-22051 22µF 50V
C408 46-10412 0.1µF 100V
C409 46-10312 0.01µF 100V
C41 45-27052 27PF 500V
C410 47-22051 22µF 50V
C411 45-39052 39PF 500V
C412 47-22051 22µF 50V
C413 45-12152 120PF 500V
C414 45-39052 39PF 500V
C42 46-47312 0.047µF 100V
C43 47-22051 22µF 50V
C44 47-22051 22µF 50V
C45 47-22051 22µF 50V
C46 47-22051 22µF 50V
C5 47-22051 22µF 50V
C6 45-18152 180PF 500V
C7 47-22151 220µF 50V
C8 46-47412 0.47µF 63V
C9 47-22051 22µF 50V
D1 61-19140 1N914 HI SPD
D10 61-40030 1N4003
D11 61-40030 1N4003
D12 61-40030 1N4003
D13 61-40030 1N4003
D14 60-50200 Diode 3A 200V
D15 60-50200 Diode 3A 200V
D16 61-40030 1N4003
D17 61-40030 1N4003
D18 60-50200 Diode 3A 200V
D19 60-50200 Diode 3A 200V
D2 61-19140 1N914 HI SPD
D20 60-50200 Diode 3A 200V
D21 60-50200 Diode 3A 200V
D22 61-40030 1N4003
D23 61-40030 1N4003
D3 61-19140 1N914 HI SPD
D4 61-19140 1N914 HI SPD
D5 60-75340 Yellow small
D6 61-40030 1N4003
D7 60-75030 BiColor Rd:Grn
D8 60-50200 Diode 3A 200V
E1 25-22204 Rot Encoder Vert
H1 23-11008 8 Pin Vert
H10 23-11002 2 Pin Vert SHS
H11 23-11004 4 Pin Vert
H2 23-11002 2 Pin Vert SHS
H3 23-11004 4 Pin Vert
H4 23-11010 10 Pin Vert
H5 23-11004 4 Pin Vert
H6 23-11008 8 Pin Vert
H7 23-11004 4 Pin Vert
H8 23-15605 Header 5V Large
H9 23-15605 Header 5V Large
J1 21-50345 Ph Jack 3P Rean
J100 21-50345 Ph Jack 3P Rean
J2 21-50345 Ph Jack 3P Rean
J200 21-50345 Ph Jack 3P Rean
J201 21-40000 XLRF Neutrik
J3 21-50345 Ph Jack 3P Rean
J300 21-50345 Ph Jack 3P Rean
J301 21-40000 XLRF Neutrik
J4 21-40020 Phono Jack x2
J400 21-50345 Ph Jack 3P Rean
J401 21-40000 XLRF Neutrik
J5 21-50345 Ph Jack 3P Rean
J6 21-06457 7 Pin Plastic
J7 21-50345 Ph Jack 3P Rean
K1 70-05505 Relay 24V5A DPDT
K2 70-05505 Relay 24V5A DPDT
OP1 60-50253 Opto Isolator
P1 71-09063 B50K D Vrt 9m35 B
P100 71-09062 B50K-C D Vt 9/35B
P101 71-09062 B50K-C D Vt 9/35B
P102 71-09062 B50K-C D Vt 9/35B
P103 71-09063 B50K D Vrt 9m35 B
P104 71-09063 B50K D Vrt 9m35 B
P2 71-09063 B50K D Vrt 9m35 B
P200 71-09062 B50K-C D Vt 9/35B
P201 71-09062 B50K-C D Vt 9/35B
P202 71-09063 B50K D Vrt 9m35 B
P203 71-09063 B50K D Vrt 9m35 B
P3 71-09063 B50K D Vrt 9m35 B
P300 71-09062 B50K-C D Vt 9/35B
P301 71-09062 B50K-C D Vt 9/35B
P302 71-09063 B50K D Vrt 9m35 B
P303 71-09063 B50K D Vrt 9m35 B
P400 71-09062 B50K-C D Vt 9/35B
P401 71-09062 B50K-C D Vt 9/35B
P402 71-09063 B50K D Vrt 9m35 B
P403 71-09063 B50K D Vrt 9m35 B
PL1 21-00041 DC Power Socket
PL2 21-02804 Jack AC W/ Fuse
Q1 60-78151 7815 +15V3A
Q2 60-15006 MTP50N06
Q3 60-15006 MTP50N06
Q4 60-15006 MTP50N06
Q5 60-15006 MTP50N06
Q6 60-78150 7815 +15V
Q7 60-79150 7915 -15V
Q8 60-00014 Darlington NPN
QC1 06-40060 QC 90° Horizontal
QC10 06-40050 QC Vertical .250
QC11 06-40050 QC Vertical .250
QC12 06-40060 QC 90° Horizontal
QC13 06-40050 QC Vertical .250
QC14 06-40050 QC Vertical .250
QC2 06-40060 QC 90° Horizontal
QC3 06-40060 QC 90° Horizontal
QC4 06-40060 QC 90° Horizontal
QC5 06-40050 QC Vertical .250
QC6 06-40060 QC 90° Horizontal
QC7 06-40060 QC 90° Horizontal
QC8 06-40060 QC 90° Horizontal
QC9 06-40050 QC Vertical .250
R1 50-47025 470Ω
R10 50-15045 15K
R100 50-15055 150K
R101 50-30055 300K
R102 50-15035 1.5K
R103 50-10045 10K
R104 50-22045 22K
R105 50-47045 47K
R106 50-15035 1.5K
R107 50-10045 10K
R108 50-12045 12K
R109 50-22045 22K
R11 50-47025 470Ω
R110 50-15045 15K
R111 50-15035 1.5K
R12 50-47025 470Ω
R13 50-10045 10K
R14 55-03305 .33Ω 5W Wire
R15 50-22045 22K
R16 50-30035 3K
R17 54-10015 10Ω 2W
R18 53-47025 470Ω 1W
R19 53-47025 470Ω 1W
R2 50-22045 22K
R20 50-10045 10K
R200 50-22055 220K
R201 50-56231 5.62K
R202 50-56231 5.62K
R203 50-15055 150K
R204 50-15055 150K
R205 50-47035 4.7K
R206 50-82035 8.2K
R207 50-10055 100K
R208 50-47035 4.7K
R209 50-10035 1K
R21 50-10045 10K
R210 50-82035 8.2K
R211 50-10045 10K
R212 50-22045 22K
R213 50-15045 15K
R214 50-22041 22K 1%
R215 50-22041 22K 1%
R22 50-82035 8.2K
R23 50-82035 8.2K
R24 50-47035 4.7K
R25 50-10035 1K
R26 50-10035 1K
R27 50-15045 15K
R28 50-15045 15K
R29 50-82035 8.2K
R3 50-47025 470Ω
R30 50-10045 10K
R300 50-22055 220K
R301 50-56231 5.62K
R302 50-56231 5.62K
R303 50-15055 150K
R304 50-15055 150K
R305 50-47035 4.7K
R306 50-82035 8.2K
R307 50-10055 100K
R308 50-47035 4.7K
R309 50-10035 1K
R31 50-10015 10Ω
R310 50-82035 8.2K
R311 50-10045 10K
R312 50-22045 22K
R313 50-15045 15K
R314 50-22041 22K 1%
R315 50-22041 22K 1%
R32 50-56231 5.62K
R33 50-24045 24K
R34 50-15045 15K
R35 50-24045 24K
R36 55-05022 0.05Ω 5W Vert.
R37 50-10035 1K
R38 50-10035 1K
R39 50-10035 1K
R4 50-10035 1K
R40 50-10035 1K
R400 50-22055 220K
R401 50-56231 5.62K
R402 50-56231 5.62K
R403 50-15055 150K
R404 50-15055 150K
R405 50-47035 4.7K
R406 50-82035 8.2K
R407 50-10055 100K
R408 50-47035 4.7K
R409 50-10035 1K
R41 50-22035 2.2K
R410 50-82035 8.2K
R411 50-10045 10K
R412 50-22045 22K
R413 50-15045 15K
R414 50-22041 22K 1%
R415 50-22041 22K 1%
R42 50-30055 300K
R43 50-47055 470K
R44 50-47035 4.7K
R45 50-68025 680Ω
R46 50-15045 15K
R47 50-10045 10K
R48 50-10045 10K
R49 50-33045 33K
R5 50-10045 10K
R50 50-22065 2.2M
R51 50-10025 100Ω
R52 50-15025 150Ω
R53 50-22025 220Ω
R54 50-10035 1K
R6 50-10045 10K
R63 50-68045 68K
R7 50-47045 47K
R8 50-47045 47K
R9 50-10045 10K
S1 25-02201 DPDT Push Vert
S2 06-40040 SwitchAC DPST QCs
U1 60-72940 TDA7294
U2 60-35260 SG3526
Z1 61-04733 Zener 5.1V
Z2 61-47450 Zener 16V
Z3 61-47450 Zener 16V
REPLACEMENT PARTS LIST (for circuit cards)
This symbol is intended to
alert the user to the pres-
ence of uninsulated “dan-
gerous voltage” within the
product’s enclosure that may be of suf-
ficient magnitude to constitute a risk of
electric shock to persons.
This symbol is
intended to alert the
user to the presence of
important operating
and maintenance (servicing) instruc-
tions in the literature accompanying
the appliance.
LIMITED WARRANTY
Your Carvin StageMate™ is guaranteed against failure for ONE YEAR unless otherwise stated. Carvin
will service and supply all parts at no charge to the customer providing the unit is under warranty.
Shipping costs are the responsibility of the customer. CARVIN DOES NOT PAY FOR PARTS OR SER-
VICING OTHER THAN OUR OWN. A COPY OF THE ORIGINAL INVOICE IS REQUIRED TO VERIFY YOUR
WARRANTY. Carvin assumes no responsibility for horn drivers or speakers damaged by this unit. This
warranty does not cover, and no liability is assumed, for damage due to: natural disasters, accidents,
abuse, loss of parts, lack of reasonable care, incorrect use, or failure to follow instructions. This war-
ranty is in lieu of all other warranties, expressed or implied. No representative or person is authorized
to represent or assume for Carvin any liability in connection with the sale or servicing of Carvin prod-
ucts. CARVIN SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.
SERVICE: In the USA, please go to www.carvin.com/cs
Outside the USA, contact your dealer or go to http://www
.carvinworld.com for your nearest service
center. Include a written description of the problem with serial number and date of purchase.
HELP SECTION
1) StageMate™ WILL NOT TURN ON
Check the power to the StageMate™. Check for tripped circuit breakers, unplugged extension cords
or power-strip switches that may be turned off. Check the fuse. If a dark brownish color or no wire
can be seen within the glass tube, then replace. The amp may be perfectly fine but occasionally a
fuse may blow because of high AC voltage surges. However, after the fuse has been replaced with
the proper Slow Blow value and if the fuse fails again, the amp will require servicing.
2) MAINTENANCE
To bring back the new look, your StageMate™ cabinet can be washed with mild detergent and/or a
warm damp soft cloth. This will remove normal dust and oil from the front and back panels. Never
spray cleaners or detergents directly at the units electronic controls. It is recommended to keep
the StageMate™ free from dust, dirt, and moisture as much as possible.
To Previous Page
Loading...
Need help?
General
