VII - 7.43
Locate the reverse switch as shown in (figure #3).
By pulling up on the reverse switch as shown in
(figure # 5) remove the reverse switch from the
switch housing as shown.
Step #2
Reverse Switch Replacement - CONTINUED
(Figure #4)
(Figure #5)
(Figure #6)
(Figure #7)
Locate the reverse switch and all of the wire nuts
attaching the reverse switch to the switch housing
as shown in (figure #6). Place the new switch next to
the old switch as shown in (figure #7). Start by
finding both the pink wires on the old and new switch
as shown, this is where will start the replacement
procedure.
Step #3
