Casablanca Fan Co. - Factory Service Department - Technical Library
VII - 7.38
First locate both the pole chain switch can
speed control capacitor block as shown in
(figure #4).
Step #1
(Figure #4)
(Figure #5)
Run Capacitor Replacement - CONTINUED
Remove the knurl nut from the pull chain
switch shown in (figure #5).
Step #2
Remove the pull chain switch and run capacitor
block from the switch housing as shown (figure
#6). The run capacitor block is held into the
switch housing by two sided tape.
Step #3
(Figure #6)
