SECTION 00 – GENERAL – CHAPTER 1
????
CONSUMABLES
COMPONENT TO BE FILLED OR
TOPPED UP
QUANTITY
CASE IH
RECOMMENDED
INTERNATIONAL
SPECIFICATION
COMPONENT TO BE FILLED OR
TOPPED UP
litres/dm
3
US gal IMP gal
RECOMMENDED
PRODUCTS
INTERNATIONAL
SPECIFICATION
Cooling system:
JX60, JX70 models
JX80, JX90, JX95 models
with cab :
JX60, JX70 models
JX80, JX90, JX95 models
12
14
14
16
3.2
3.7
3.7
4.2
2.64
3.08
3.1
3.5
Water & liquid
AKCELA PREMIUM
ANTI–FREEZE
50% + 50%
–
Windscreen washer bottle . . . . . . . . . . 2 0.53 0.44
Water & cleaning
liquid
–
Fuel tank 90 23.8 19.8
Decanted and filtered
–
Additional fuel tank (Optional) . . . . . . . 27 7.1 5.94
Decanted and filtered
diesel fuel
–
Engine sump:
without filter :
JX60, JX70 models
JX80, JX90, JX95 models
with filter :
JX60, JX70 models
JX80, JX90, JX95 models
7.6
10.5
8.3
11.2
1.98
2.77
2.19
2.96
1.67
2.31
1.83
2.46
AKCELA No.1
ENGINE OIL
API CH–4 * ACEA
E5 * MB 228.3 *
CUMMINS CES
200072/20076/20077
API CF–4/SG
CCMC D4
MIL–L–2104E
Brake control circuit . . . . . . . . . . . . . . . . 0.4 0.1 0.09
AKCELA LHM
FLUID Oil
ISO 7308
Hydrostatic steering circuit . . . . . . . . . . 2.0 0.5 0.44
Front axle:
– axle housing :
JX60, JX70 models
JX80, JX90, JX95 models
– final drives (each) :
JX60, JX70 HP models
JX80, JX90, JX95 models
4.5
7.0
0.8
1.25
1.2
1.8
0.2
0.3
0.99
1.54
0.18
0.28
Rear transmission (bevel drive and
brakes), gearbox, hydraulic lift and
PTO
JX60, JX70, JX80, JX90,
JX95 models . . . . . . . . . . . . . . . . . .
– with synchro–reverser:
JX60, JX70, JX80, JX90,
JX95 models . . . . . . . . . . . . . . . . . .
46
46
12.15
12.15
10.12
10.12
Oil
AKCELA
NEXPLORE
API GL4
ISO 32/46
SAE 10W–30
Rear final drives (each) :
JX60, JX70 HP models
JX80, JX90, JX95 models
3.9
5.3
1.03
1.40
0.86
1.17
Front wheel hubs . . . . . . . . . . . . . . . . . . – – –
Grease
AKCELA
MULTI–PURPOSE
NLGI 2
Grease fittings . . . . . . . . . . . . . . . . . . . . – – –
MULTI–PURPOSE
GREASE
(251H EP)
NLGI 2
