2 - IDENTIFICATION NUMBERS
6
RH08E036
Rh08e038
1
2
3
4
5
6
7
8
9
10
1. ENGINE COMPARTMENT
2. RIGHT SIDE PANELS
3. RIGHT SIDE SERVICE DOOR
4. ROTOR HOUSING (INTERNAL)
5. SERVICE LADDER
6. OPERATOR’S PLATFORM HANDRAILS
7. ELEVATORS
8. STATIONARY AIR SCREEN
9. RIGHT SIDE OPERATOR’S PLATFORM
10. REAR BEACON
11. STRAW SPREADER 15. TURN SIGNALS
12. REAR ACCESS LADDER 16. STOP LAMPS
13. HOOP GUARD 17. TAIL LAMPS
14. STEERING AXLE 18. REFLECTOR
11
12
13
14
15
16
17
18
