Case IH FARMALL 45C CVT User Manual

INTRODUCTION
Farmall40Farmall45Farmall50
BRAKES
Type......WetDiscWetDisc
3DiscDiameter....175mmx143mm
Diameter(6.9inx5.6in)
175mmx143mm
Diameter(6.9inx5.6in)
175mmx143mm
Diameter(6.9inx5.6in
STEERING
Type........PowerPowerPower
PumpFlow@Rated
RPM.......
19.34l/min(5.11USgpm)19.34l/min(5.11USgpm)19.34l/min(5.11USgpm)
Turns
Lock-to-Lock:
FWD.........4.3RtoLand3LtoR4.3RtoLand3LtoR34.3RtoLand3LtoR
SuperSteer......
4.34.34.3
FrontWheelT oe-In....
.....
0-5mm(0-13/64in)0-5mm(0-13/64in)0-5mm(0-13/64in)
TurningRadiusw/oBrakes:
FWD..........
3238.5mm(127.5in)3238.5mm(127.5in)3238.5mm(127.5in)
SuperSteer......2870.2mm(113in)2870.2mm(113in)2870.2mm(113in)
Max.TurnAngle........
4WD
54°54°54°
4WDSS75°75°75°
Fronttorearaxleratio.
.....
1.67to11.67to11.67to1
POWERTAKE-OFF
Type.....IndependentIndependentIndipendent
Shaft:
RearPTO...35mm(1-3/8in)35mm(1-3/8in)35mm(1-3/8in)
MidPTO.......25.4mm(1in)25.4mm(1in)25.4mm(1in)
EngineSpeedfor
540RPMRear
PTOOperation...
2409RPM-2409RPM-2409RPM
HorsepowerRearPTO
Observed.....
23kW(30.8Hp)25.8kW(34.6Hp)28.7kW(38.5Hp)
HorsepowerMidPTO
Observed..
19.3kW(26Hp)22.3kW(30Hp)24.6kW(36Hp)
EngineSpeedfor
2000RPMMid
PTOOperation...
2407RPM2407RPM2407RPM
DirectionofRotation(As
viewedfromrearoftract)
...RearPTO.......ClockwiseClockwiseClockwise
MidPTO........Counter-clockwiseCounter-clockwiseCounter-clockwise
HYDRAULICLIFT
SYSTEM
Type......
OpenCenterOpenCenter
PumpType...
GearGear
PumpCapacity.36.9l/min(9.7USgpm)36.9l/min(9.7USgpm)39.8l/min(10.5USgpm)
SystemReliefValve
Setting.........
171.6bar(2488psi)171.6bar(2488psi)171.6bar(2488psi)
NumberofRearRemotes
Available.
3(optional3(optional3(optional
NumberofMidRemotes
Available.
2(optional)2(optional)2(optional)
4785194503/02/2016
42
