HYDRAULIC-PNEUMATIC-ELECTRICAL-ELECTRONICSYSTEMS-PRIMARYHYDRAULICPOWER
SYSTEM
TractorsWithMechanicalHydraulicLift
HydraulicLiftOperating
SteeringSystem
Oil
SystemPressure
Oil
TrappedOil
LowPressure
CircuitOil17-18
bar(246-261
lbf/in²)
Returnto
ReservoirOil
LubricationOil
SuctionOil
1.LiftControlValve2.LiftCylinderSafetyValve
3.MechanicalHydraulicLiftAssembly4.SteeringMotor
5.LowPressureCircuitPressureRegulatingValve6.SteeringandLowPressureCircuitGearPump
7.FixedDisplacementPump
8.PressureReliefValve(195-205Bar)
9.SubplatewithPressureCompensator
10.TrailerBrakeValve
84276322A31/05/2010
A.10.A/
35
