HYDRAULIC-PNEUMATIC-ELECTRICAL-ELECTRONICSYSTEMS-PRIMARYHYDRAULICPOWER
SYSTEM
VariableDisplacementPumpClosedCentreLoadSensingHydraulicCircuit24x24Models
1T oAdditionalRemoteControlValves2EndPlateWithLoadSensingShuttleValve
3VariableDisplacementHydraulicPump
4MidMountedRemoteControlValve
5LowPressureSwitch6BoostedLubricationOil
7FrontSuspensionControlValve
8TrailerBrakeValve
9PowerBeyondPorts
10SubplatewithLowPressureCompensatorValve
11FeedtoLowPressurecircuit
12LiftCylinder
13ElectronicDraftControlValve14RemoteControlValve
AHighPressureCircuitOilBSteeringCircuit
CLowPressureCircuitOilDTrappedOil
EReturnT oReservoirOilFSuctionOil
GChargePumpOilHLubricationOil
84276322A31/05/2010
A.10.A/
38
