Case IH MAXXUM 115 - Fuse Box and Electrical Connector Disconnections

Engine-Engineandcrankcase
9.Detachthefusebox.
A.Removetheretainingnuts.
B.Detachthewiringharnessesfromtheretaining
clips.
BAIL14TR00935AB9
10.
•
Disconnectthealternatorelectricalconnector.
•
Disconnectthein-lineelectricalconnector.
BAIL14TR00936AB10
11.Removethesidepanelmountingbracket.
BAIL14TR00937AB11
12.Removethestartermotorshield.
A.Cutthecableties.
B.Removethestartermotorshieldretainingbolts.
BAIL14TR00938AB12
