Engine-Engineandcrankcase
7.A.Installtheenginetotransmissionlowerinnerre-
tainingbolts.
B.Torqueto285-315Nm(210-232lbft).
BAIL14TR00968AB6
8.Installthesmallerwheeledpartofthetractorsplitting
stand380003352undertheengine.
BAIL15TR00025AA7
9.Removethesupportfromtherearofthevehicle.
BAIL07APH145AVA8
10.Removetheliftingequipmentfromtheengine.
BAIL07APH144AVA9
4793872419/10/2015
10.1[10.001]/53
