Case IH MC3100PR - Generator Components

LOW OIL INDICATOR
TÉMOIN DE NIVEAU D’HUILE
13
Read this operator’s manual and safety
rules before operating your generator.
generator components
1. Control Panel
2. Fuel Tank
3. Fuel Gauge
4. Oil Drain Plug
5. Recoil Starter
6. Tank Cap
7. Frame
8. Air Cleaner
9. ON/OFF Switch
1.
14.
15.
16.
5.
8.
4. 9. 10. 13.
17. 12. 11.
2.6.7. 3.
10. DC Connection
11. DC Breaker
12. Hourmeter
13. 120V 3 Prong Twistlock
14. Ground
15. 120V GFCI
16. AC Breaker
17. Oil Dipstick
