Case 1021G - Engine Removal

Engine-Engineandcrankcase
Engine-Remove
Prioroperation:
Enginehood-Remove(90.105)
1.Parkthemachineonalevelsurfaceandlowerthe
buckettotheground.Putthearticulationlock(1)in
LOCKEDposition.
LEIL15WHL1782AA1
2.Pushthehydraulicfunctionslock-outswitchinthenor-
maloperationposition.
LEIL16WHL1125AA2
3.Movetheloaderhydrauliccontrolhandletotheraise
andlowerpositioninordertoreleaseanyhydraulic
pressureintheliftcircuit.
4.Movetheloadercontrolhandleinandoutofthetilt
positionseveraltimes,thiswillrelieveanypressurein
thepilotaccumulator.
5.Releasethepressureintheridecontrolaccumulator
withthebleedervalveintheridecontrolvalveload
travelstabilizer.
6.Actuatethebrakepedalseveraltimestodischarge
brakeaccumulators.
LEIL15WHL0564AA3
48083742_EN31/07/2018
10.1[10.001]/4
