SECTION 00 - GENERAL INFORMATION - CHAPTER 1
00-9
COMBINE INTERNATIONAL SYMBOLS
As a guide to the operation of your combine, various universal symbols have been utilized on the instruments, con-
trols, switches, and fuse box. The symbols are shown below with an indication of their meaning.
Header height
Warning
Upper
Sieve
Engine heater
Slow
Fast
Engine coolant
temp
Fuel
Electric
Headlights
Vertical
Knives
Power Rear Axle
Work lights rear
Field/Road
Mode
Hazard light
Turn left
Headlights dimmed
Work lights fore
Turn right
Header Auger
Rotor Speed
Park brake
Header
Header Height
Lower
Sieve
Reel RPM
Concave
position
Cleaning fan
Unloading
