410/420 SKID STEER AND 420CT COMPACT TRACK LOADER
Repair Manual
Mechanical and Pilot Control Machines
(Tier 3 and Cab Up-Grade Machines)
Bur 87634765
Table of Contents
Copyright © 2007 CNH America LLC.
All rights reserved.
Printed in U.S.A.
Issued February, 2005 (Revised December, 2007)
CNH AMERICA LLC.
700 State Street
Racine, WI 53404 U.S.A.
Bur 6-78992
Description Section Number
Publication
Form Number
General Tab 1
Section Index - General 6-79041
Fluids and Lubricants 1001 6-79031
Fluids and Lubricants Tier 3 Engines 1001 5-7580
Standard Torque Specifications 1002 7-52931
Metric Conversion Chart 1003 7-52950
Engines Tab 2
Section Index - Engines 6-79051
Engine and Radiator Removal and Installation 2000 6-79130
Engine and Radiator Removal and Installation (410 Tier 3 Engines) 2000 5-7650
Engine and Radiator Removal and Installation (420/420CT Tier 3 Engines) 2000 5-7660
For Engine Repair - See Engine Repair Manual 6-79550
For 420/420CT Tier 3 Engine Repair - See Tier 3 Engine Repair Manual 87693888
Fuel Systems Tab 3
Section Index - Fuel Systems 6-79061
For Fuel System Repair - See the Engine Repair Manual 6-79550
For 420/420CT Tier 3 Fuel System Repair - - See Tier 3 Engine Repair Manual 87693888
Electrical Tab 4
Section Index - Electrical 6-79071
Electrical Specifications and Troubleshooting and Schematics 4001 6-79540
Electrical Specifications and Troubleshooting and Schematics (Tier 3 Cab
Up-Grade Machines)
4001 5-9590
Battery 4005 7-51310
Starter and Starter Solenoid 4006 7-53091
Tracks
Tab 5
Section Index - Tracks 5-2631
Tracks 5001 5-2610
Drive Sprocket, Idler Wheels, and Rollers 5002 5-2620
Track Drive Motor 5003 5-7630
