Bur 6-78992 Revised 12-07 Printed in U.S.A.
410/420 SKID STEER AND 420CT COMPACT TRACK LOADER
Repair Manual
Mechanical and Pilot Control Machines
(Tier 3 and Cab Up-Grade Machines)
Bur 87634765
Table of Contents (Continued)
Mounted Equipment Tab 9
Section Index - Mounted Equipment 6-79111
Pedals and Levers 9001 6-79500
Pedals and Levers (Cab Up-Grade Machines) 9001 5-7670
Loader 9002 6-79390
Attachment Coupler 9003 6-79400
ROPS Canopy, Seat, Seat Belts, and Operators Compartment 9004 6-79410
ROPS Canopy, Seat, Seat Belts, and Operators Compartment (Cab Up-Grade
Machines)
9004 5-9460
Heater 9006 6-79450
Air Conditioning Troubleshooting for Systems with R134A Refrigerant
(Cab Up-Grade Machines)
9011 5-9480
Air Conditioner System Gauges and Testing for Systems with R134A
Refrigerant
(Cab Up-Grade Machines)
9012 5-9490
Refrigerant Recovery, Compressor Removal and System Evacuation
and Recharging
(Cab Up-Grade Machines)
9013 5-9500
Air Conditioner System Gauges and Testing for Systems with R134A
Refrigerant
(Cab Up-Grade Machines)
9014 5-9510
Schematic Set
Hydraulic and Electrical Schematic Foldout In Rear Pocket 6-78971
Hydraulic and Electrical Schematic Foldout (Tier 3 - Cab Up-Grade and
Machines Equipped with Pilot Controls)
In Rear Pocket 5-9610
