Case 570ST - Engine and Crankcase; Engine Removal Procedure

Engine-Engineandcrankcase
Engine-Remove
Prioroperation:
RefertoBasicinstructions()
Prioroperation:
RefertoHood-Remove(90.100)
Prioroperation:
RefertoRadiator-Remove(10.400)
Prioroperation:
RefertoIntakeandexhaustmanifoldsandmufer-Remove(10.254)
NOTE:Putidenticationtagsonalldisconnectedhoses
andwires.Closealldisconnectedhosesandttingswith
capsandplugsimmediately.
NOTE:Theimagesinthisproceduremaybedifferentfrom
yourmachineandareforreferenceonly.
ATTENTION:Allowtheenginetoreachnormaltempera-
turebeforeperforminganyserviceormaintenanceproce-
dure.Wearsafetyglovesandgogglesforprotectionfrom
hotcomponentsanduidsorsevereburnscouldresult.
1.Drainengineoilbylooseningthedrainnut.Collectthe
oilinacleancontainer,capitandkeepitasideina
cleanplace.
2.Disconnectthefuelreturnandinletlines(1)fromthe
mudlter(4)andcapthemimmediately.
Loosenthemountingbolts(2)andremovetheassem-
bly(3)fromthemachine.
PTIL13TLB0953AB1
3.Removetheexhaustpipe(1)oftheturbochargerand
capit.
PTIL13TLB0956AB2
4804855616/09/2016
10.1[10.001]/3
