6-WORKINGOPERATIONS

4.Installthesafetystrut(2)inthestoragepositiononthe

loaderarmbymeansofthesplitpins(1).

5.Starttheengineandlowertheloaderattachment.

MOLI12LBB0264AB8

6-13
